Car Wiring Diagrams for Starting circuit, hatchback w/o keyless access system for Honda Civic Type R X (2015-2021)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 1-7 FUSE 18 FUSE 2-2 FUSE 3-5 GRN WIRE GRY WIRE LT BLU WIRE PCM PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RELAY CIRCUIT BOARD SHIFT POSITION INDICATOR STARTER CUT RELAY 1 STARTER CUT RELAY 2 TOP OF TRANSMISSION) TRANSMISSION CONTROL MODULE TRANSMISSION RANGE SWITCH (CVT) (TOP LEFT SIDE OF TRANSMISSION) UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BATTERY BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE CLUTCH PEDAL POSITION SWITCH A COMPUTER DATA LINES SYSTEM FUSE 21 FUSE 30 GRN WIRE HOT IN ON OR START IGNITION SWITCH LOCK M/T MAGNETIC SWITCH PNK WIRE RED WIRE STARTER UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE
