Car Wiring Diagrams for Power windows circuit for Honda Civic Type R X (2015-2021)

AS IND AUTO DOWN AUTO UP BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL UNIT) DR IND DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ KEY CYLINDER SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S POWER WINDOW MOTOR DRIVER'S SWITCH FRONT PASSENGER'S SWITCH FUSE 14 FUSE 15 FUSE 18 FUSE 2-4 FUSE 27 FUSE 28 FUSE 9 GRN WIRE HOT AT ALL TIMES HOT W/ LEFT REAR SWITCH LR IND (SEDAN) LT BLU WIRE LT GRN WIRE MAIN IND MAIN SWITCH MOONROOF CONTROL UNIT/MOTOR PNK WIRE POWER WINDOW MASTER SWITCH PPL PULSER RED WIRE RIGHT REAR SWITCH RR IND (SEDAN) SEDAN UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

AUTO DOWN AUTO UP BLK WIRE BLU WIRE BRN WIRE CONTROL UNIT) CVT CVT M/T DOWN FRONT PASSENGER'S POWER WINDOW SWITCH GRN WIRE HATCHBACK COUPE, SEDAN IND LEFT REAR POWER WINDOW MOTOR LT BLU WIRE LT GRN WIRE M/T OFF PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH PASSENGER'S POWER WINDOW MOTOR PNK WIRE PPL PULSER RED WIRE RIGHT POWER MIRROR RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH (SEDAN) TAN WIRE UP OFF W/ HEATED MIRRORS W/O HEATED MIRRORS WHT WIRE YEL WIRE
