Car Wiring Diagrams for Heated seats circuit, coupe for Honda Civic Type R X (2015-2021)

ADAPTIVE DAMPER CONTROL UNIT BLK WIRE BLU WIRE BREAKER BRN WIRE CLIMATE CONTROL PANEL CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION DRIVER'S SEAT CUSHION HEATER DRIVER'S SEAT HEATER DRIVER'S SEAT- BACK HEATER FRONT PASSENGER'S SEAT BACK HEATER FRONT PASSENGER'S SEAT CUSHION HEATER FRONT PASSENGER'S SEAT HEATER FRONT SEAT HEATER CONTROL UNIT FRONT SEAT HEATER RELAY FUSE 32 FUSE 5 FUSE 9 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON HOT IN ON OR START LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE RIGHT END OF DASH) THERMISTOR UNDER-DASH FUSE/RELAY BOX YEL WIRE
