Car Wiring Diagrams for Electronic suspension circuit, hatchback for Honda Civic Type R X (2015-2021)

ADAPTIVE DAMPING CONTROL UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 31 FUSE 5 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT FRONT SUSPENSION STROKE SENSOR LEFT REAR SUSPENSION STROKE SENSOR LT GRN WIRE PNK WIRE PPL RED WIRE RELAY ENERGIZED RIGHT FRONT SUSPENSION STROKE SENSOR RIGHT REAR SUSPENSION STROKE SENSOR UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY HOLDER B WHT WIRE YEL WIRE

BLU WIRE BRN WIRE FRONT ACCELERATION SENSOR GRN WIRE GRY WIRE LEFT FRONT DAMPER ACTUATOR LEFT REAR ACCELERATION SENSOR LEFT REAR DAMPER ACTUATOR LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RIGHT FRONT DAMPER ACTUATOR RIGHT REAR ACCELERATION SENSOR RIGHT REAR DAMPER ACTUATOR WHT WIRE YEL WIRE
