Car Wiring Diagrams for 1.5l turbo, cruise control circuit for Honda Civic Type R X (2015-2021)

1.5L TURBO 2.0L 2.0L APP SENSOR APP SENSOR A APP SENSOR B BLK WIRE BLU WIRE BODY CONTROL MODULE BRAKE LIGHT RELAY BRAKE PEDAL POSITION SWITCH BRN WIRE COMPUTER DATA LINES SYSTEM COUPE COUPE, SEDAN HATCHBACK CVT SPEED SENSOR FUSE 7 FUSE 9 FUSE 8 GRN WIRE GRY WIRE HATCHBACK HOT AT ALL TIMES LT GRN WIRE OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR PCM PGM-FI MAIN RELAY 1 PNK WIRE PPL PPL/GRN WIRE PPL/GRY WIRE RED WIRE RELAY CIRCUIT BOARD SEDAN TAN WIRE THERMAL JOINT 1 THROTTLE ACTUATOR THROTTLE BODY (RIGHT REAR OF ENGINE) THROTTLE OPEN SENSOR TRANSMISSION CONTROL MODULE TRANSMISSION RANGE SWITCH UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

1.5L TURBO W/O ADAPTIVE CRUISE CONTROL 2.0L W/O ADAPTIVE CRUISE CONTROL ACC COMBINATION SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL CANCEL SWITCH COMPUTER DATA LINES SYSTEM COUPE HATCHBACK COUPE, SEDAN CRUISE CONTROL INDICATOR CRUISE MAIN INDICATOR DIMMING CIRCUIT DISTANCE SWITCH F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE 21 FUSE 34 FUSE 5 FUSE 7 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HATCHBACK HOT IN ON OR START LKAS SWITCH LT BLU WIRE LT GRN WIRE MAIN SWITCH MILLIMETER WAVE RADAR UNIT PNK WIRE RED WIRE RES/+ SWITCH SEDAN SET SWITCH TAN WIRE UNDER-DASH FUSE/RELAY BOX VSA MODULATOR CONTROL UNIT W/ ADAPTIVE CRUISE CONTROL W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM WARNING DRIVE CIRCUIT WHT WIRE YEL WIRE
