Honda Civic Type R X (2015-2021) wht Wiring diagrams
This page contains all the electrical diagrams for the component. wht, in which he is found in the car Honda Civic Type R X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wht (191 of 242)
A/C PRESSURE SENSOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
EVAP CANISTER VENT SHUT VALVE
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 27
GAUGE CONTROL MODULE
GRN WIRE
INJECTORS 1, 2, 3, 4 (UNDER INTAKE MANIFOLD, AT 1, 2, 3, 4 CYLINDERS)
LT BLU WIRE
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
PNK WIRE
PPL
RED WIRE
TAN WIRE
THERMAL JOINT 2
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER A
WARNING DRIVING CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, except si (2 of 6) -> WHT WIRE
Wiring diagram wht (192 of 242)
AIR CONDITIONING
BLK WIRE
BLU WIRE
BRN WIRE
CPU/IPD
FAN MOTOR
FUSE 1-3
FUSE 10
FUSE 12
FUSE 9
GRN WIRE
HIGH PRESSURE FUEL PUMP
HOT AT ALL TIMES
INJECTOR RELAY
KNOCK SENSOR
LT BLU WIRE
LT GRN WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PPL
RED WIRE
RFC RELAY
RFC UNIT
SYSTEM
TAN WIRE
THERMAL JOINT 1
THERMAL JOINT 2
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER B
UNDER-HOOD RELAY HOLDER A
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, except si (3 of 6) -> WHT WIRE
Wiring diagram wht (193 of 242)
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
IAT SENSOR 2
ICM
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LT BLU WIRE
M/T
NEUTRAL POSITION SENSOR
OIL PRESSURE SWITCH
PNK WIRE
PPL
RED WIRE
REVERSE LOCKOUT SOLENOID
SPARK PLUG
TURBOCHARGER
TURBOCHARGER BOOST SENSOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR POSITION SENSOR
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, except si (5 of 6) -> WHT WIRE
Wiring diagram wht (194 of 242)
APP SENSOR A
APP SENSOR A/B (TOP OF ACCELERATOR PEDAL ASSEMBLY)
APP SENSOR B
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CLUTCH PEDAL POSITION SWITCH A
COMPUTER DATA LINES SYSTEM
CVT
FTP SENSOR
FUSE 11
FUSE 15
FUSE 17
FUSE 4
FUSE 5
FUSE 7
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
M/T
PCM
PGM-FI MAIN RELAY 2
PNK CVT WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RLY ENERGIZED
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
THERMAL JOINT 2
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
W/ M/T
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, hatchback (1 of 6) -> WHT WIRE
Wiring diagram wht (195 of 242)
A/C PRESSURE SENSOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION C
EVAP CANISTER VENT SHUT VALVE
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 33
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
IMMOBILIZER KEYLESS CONTROL UNIT
INJECTORS 1, 2, 3, 4 (UNDER INTAKE MANIFOLD, AT 1, 2, 3, 4 CYLINDERS)
LT BLU WIRE
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
PNK WIRE
PPL
RED WIRE
TAN WIRE
THERMAL JOINT 2
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER B
W/ 14 PIN CONNECTOR
W/ 18 PIN CONNECTOR
W/ IMMOBILIZER
WARNING DRIVING CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, hatchback (2 of 6) -> WHT WIRE
Wiring diagram wht (196 of 242)
AIR CONDITIONING
BLK WIRE
BLU WIRE
BRN WIRE
CPU/IPD
FAN MOTOR
FUSE 1-3
FUSE 10
FUSE 12
FUSE 8
GRN WIRE
GRY WIRE
HIGH PRESSURE FUEL PUMP
HOT AT ALL TIMES
INJECTOR RELAY
KNOCK SENSOR
LT BLU WIRE
LT GRN WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PPL
RED WIRE
RFC RELAY
SYSTEM
TAN WIRE
THERMAL JOINT 1
THERMAL JOINT 2
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER B
UNDER-HOOD RELAY HOLDER A
W/ 14 PIN CONNECTOR
W/ 18 PIN CONNECTOR
WHT WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, hatchback (3 of 6) -> WHT WIRE
Wiring diagram wht (197 of 242)
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
IAT SENSOR 2
ICM
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
LT BLU WIRE
M/T
NEUTRAL POSITION SENSOR
OIL PRESSURE SWITCH
PNK WIRE
PPL
RED WIRE
REVERSE LOCKOUT SOLENOID
SPARK PLUG
TURBOCHARGER
TURBOCHARGER BOOST SENSOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR
TURBOCHARGER WASTEGATE CONTROL ACTUATOR POSITION SENSOR
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, hatchback (5 of 6) -> WHT WIRE
Wiring diagram wht (198 of 242)
A/F SENSOR (SENSOR 1) (ON EXHAUST MANIFOLD)
BLK WIRE
BLU WIRE
BRN WIRE
CMP SENSOR A
ECT SENSOR 2
EVAP CANISTER PURGE VALVE
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
MAF SENSOR/ IAT SENSOR 1
PCM
PNK WIRE
PPL
RED WIRE
THERMAL JOINT 1
THERMAL JOINT 2
THROTTLE ACTUATOR
THROTTLE OPEN SENSOR
TRANSMISSIONS SYSTEM
TURBOCHARGER BYPASS CONTROL SOLENOID VALVE
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
W/ 14 PIN CONNECTOR
W/ 18 PIN CONNECTOR
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, hatchback (6 of 6) -> WHT WIRE
Wiring diagram wht (199 of 242)
APP SENSOR A
APP SENSOR A/B (TOP OF ACCELERATOR PEDAL ASSEMBLY)
APP SENSOR B
AUDIO UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CLUTCH PEDAL POSITION SWITCH A
COMPUTER DATA LINES SYSTEM
FTP SENSOR
FUSE 11
FUSE 15
FUSE 5
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
LT GRN WIRE
PCM
PGM-FI MAIN RELAY 2
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RELAY ENGERGIZED
SEDAN COUPE W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
STARTING/ CHARGING SYSTEM
STARTING/CHARGING SYSTEM
TAN WIRE
THERMAL JOINT 2
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, si (1 of 6) -> WHT WIRE
Wiring diagram wht (200 of 242)
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRN WIRE
CKP SENSOR
CMP SENSOR B
ECT SENSOR 1
FUEL RAIL PRESSURE SENSOR
FUSE 21
GRN WIRE
GRY WIRE
HOT W/
IGNITION COIL RELAY
LT BLU WIRE
LT GRN WIRE
MAP SENSOR
OUTPUT SHAFT (COUNTER- SHAFT) SPEED SENSOR
PGM-FI MAIN RELAY 1
PGM-FI SUB- RELAY
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD
RELAY ENERGIZED
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.5l turbo, si (4 of 6) -> WHT WIRE
