Honda Civic Type R X (2015-2021) lanewatch camera Wiring diagram
This page shows the only wiring diagram for the component.lanewatch camera, which is found in the car Honda Civic Type R X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lanewatch camera (1 of 1)
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COUPE, SEDAN
FUSE 19
GRN WIRE
GRY WIRE
HATCHBACK
HATCHBACK W/ DISPLAY AUDIO, SEDAN W/ NAVIGATION
HOT AT ALL TIMES
LANE WATCH SWITCH
LANEWATCH CAMERA
ORG/ WIRE
RED WIRE
RIGHT POWER MIRROR
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Lane watch camera circuit -> LANEWATCH CAMERA
