Honda Civic Type R X (2015-2021) lane watch switch Wiring diagram
This page shows the only wiring diagram for the component.lane watch switch, which is found in the car Honda Civic Type R X (2015-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane watch switch (1 of 1)
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COUPE, SEDAN
FUSE 19
GRN WIRE
GRY WIRE
HATCHBACK
HATCHBACK W/ DISPLAY AUDIO, SEDAN W/ NAVIGATION
HOT AT ALL TIMES
LANE WATCH SWITCH
LANEWATCH CAMERA
ORG/ WIRE
RED WIRE
RIGHT POWER MIRROR
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Lane watch camera circuit -> LANE WATCH SWITCH
