Honda Civic Type R X (2015-2021) gry Wiring diagrams
This page contains all the electrical diagrams for the component. gry, in which he is found in the car Honda Civic Type R X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram gry (151 of 221)
2.0L
A/F SENSOR (SENSOR 1) SHIELD
BATTERY
BATTERY SENSOR
BLK WIRE
BLOWER MOTOR RELAY
BRN WIRE
ENGINE
EPS CONTROL UNIT
GRY WIRE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KNOCK SENSOR SHIELD
LEFT FOG LIGHT
LEFT FRONT PARKING/ DAYTIME RUNNING LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
MILLIMETER WAVE RADAR UNIT
PCM
RFC UNIT
ROCKER ARM OIL CONTROL SOLENOID
ROCKER ARM OIL PRESSURE SWITCH
SRS UNIT
THERMAL JOINT 1
THERMAL JOINT 2
THERMAL JOINT 3
TRANSMISSION HOUSING)
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX RELAY CIRCUIT BOARD
VSA MODULATOR CONTROL UNIT
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit, coupe (1 of 5) -> GRY WIRE
Wiring diagram gry (152 of 221)
1.5L TURBO 2.0L
A/F SENSOR (SENSOR 1) SHIELD
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CANADA
CLUTCH PEDAL POSITION SWITCH A
COUPE
CVT
GRY WIRE
HIGH PRESSURE FUEL PUMP SHIELD
HOOD LATCH SWITCH
HORN (HIGH)
HORN (LOW)
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
KNOCK SENSOR SHIELD
LEFT FRONT SIDE MARKER LIGHT
M/T
MILLIMETER WAVE RADAR UNIT
PCM
POWER TRANSISTOR
REAR WINDOW DEFOGGER
RIGHT FOG LIGHT
RIGHT FRONT PARKING/ DAYTIME RUNNING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
SEDAN
THERMAL JOINT 2
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SWITCH
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER MOTOR
Go to component -> Ground distribution circuit, coupe (2 of 5) -> GRY WIRE
Wiring diagram gry (153 of 221)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COUPE
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT SEAT HEATER CONTROL UNIT
GRY WIRE
INNER TAILLIGHT
KEYLESS BUZZER
LEFT "C" PILLAR)
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SEAT HEATER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT
RIGHT INNER TAILLIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SEAT HEATER SWITCH
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT
SEDAN
SEDAN, COUPE
TRUNK LID LATCH
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
WIRELESS CHARGER
Go to component -> Ground distribution circuit, coupe (5 of 5) -> GRY WIRE
Wiring diagram gry (154 of 221)
2.0L TURBO
BATTERY
BATTERY SENSOR
BLK WIRE
BRN WIRE
ENGINE
EPS CONTROL UNIT
GRY WIRE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KNOCK SENSOR SHIELD
LEFT FOG LIGHT
LEFT FRONT PARKING/ DAYTIME RUNNING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
NO. 2
PCM
RFC UNIT CPU/ IPD
ROCKER ARM OIL CONTROL SOLENOID
ROCKER ARM OIL PRESSURE SWITCH
SRS UNIT
THERMAL JOINT 1
THERMAL JOINT 3
THERMAL JOINT 4
TRANSMISSION HOUSING)
VSA MODULATOR CONTROL UNIT
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
W/ LED
W/O LED
Go to component -> Ground distribution circuit, hatchback (1 of 5) -> GRY WIRE
Wiring diagram gry (155 of 221)
2.0L TURBO
A/C CONDENSER FAN MOTOR
BATTERY MOTOR RELAY
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CANADA
CLUTCH PEDAL POSITION SWITCH A
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT HEATER
DRIVER'S SEAT POSITION SENSOR
FAN CONTROL RELAY
FRONT ACCESSORY POWER SOCKET RELAY
FUEL TANK UNIT
GRY WIRE
HOOD LATCH SWITCH
HORN (HIGH)
HORN (LOW)
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR SEAT CUSHION HEATER
M/T
MILLIMETER WAVE RADAR UNIT
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
POWER TRANSISTOR
REAR WINDOW WASHER MOTOR RELAY
RELAY CIRCUIT BOARD
RIGHT FOG LIGHT
RIGHT FRONT PARKING/ DAYTIME RUNNING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
RIGHT REAR SEAT CUSHION HEATER
TAILGATE RELEASE ACTUATOR RELAY
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD RELAY HOLDER B
W/ KEYLESS ACCESS SYSTEM
W/ LED W/O LED W/ POWER SEATS W/O POWER SEATS
W/O KEYLESS ACCESS SYSTEM
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER CONTROL UNIT/MOTOR
YEL WIRE
Go to component -> Ground distribution circuit, hatchback (2 of 5) -> GRY WIRE
Wiring diagram gry (156 of 221)
ADAPTIVE DAMPER CONTROL UNIT
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
ELECTRIC STEERING LOCK
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
GRY WIRE
HIGH MOUNT BRAKE LIGHT
LEFT "C" PILLAR)
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT
LEFT INNER TAIL- LIGHT
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SEAT HEATER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAIL LIGHT
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT INNER TAIL LIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SEAT HEATER SWITCH
STEERING LOCK
TAILGATE LATCH
TAILGATE OUTER HANDLE/ LOCK SWITCH/ LICENSE PLATE LIGHT
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SWITCH
W/O ELECTRIC STEERING LOCK
W/O KEYLESS ACCESS SYSTEM W/ KEYLESS ACCESS SYSTEM
Go to component -> Ground distribution circuit, hatchback (5 of 5) -> GRY WIRE
Wiring diagram gry (157 of 221)
2.0L
A/F SENSOR (SENSOR 1) SHIELD
BATTERY
BATTERY SENSOR
BLK WIRE
BLOWER MOTOR RELAY
BRN WIRE
ENGINE
EPS CONTROL UNIT
GRY WIRE
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KNOCK SENSOR SHIELD
LEFT FOG LIGHT
LEFT FRONT PARKING/ DAYTIME RUNNING LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
MILLIMETER WAVE RADAR UNIT
PCM
RFC UNIT
ROCKER ARM OIL CONTROL SOLENOID
ROCKER ARM OIL PRESSURE SWITCH
SRS UNIT
THERMAL JOINT 1
THERMAL JOINT 2
THERMAL JOINT 3
TRANSMISSION HOUSING)
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX RELAY CIRCUIT BOARD
VSA MODULATOR CONTROL UNIT
VTC OIL CONTROL SOLENOID VALVE A
VTC OIL CONTROL SOLENOID VALVE B
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit, sedan (1 of 5) -> GRY WIRE
Wiring diagram gry (158 of 221)
1.5L TURBO 2.0L
A/F SENSOR (SENSOR 1) SHIELD
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CANADA
CLUTCH PEDAL POSITION SWITCH A
COUPE
CVT
GRY WIRE
HIGH PRESSURE FUEL PUMP SHIELD
HOOD LATCH SWITCH
HORN (HIGH)
HORN (LOW)
INJECTOR 1 SHIELD
INJECTOR 2 SHIELD
INJECTOR 3 SHIELD
INJECTOR 4 SHIELD
KNOCK SENSOR SHIELD
LEFT FRONT SIDE MARKER LIGHT
M/T
MILLIMETER WAVE RADAR UNIT
PCM
POWER TRANSISTOR
REAR WINDOW DEFOGGER
RIGHT FOG LIGHT
RIGHT FRONT PARKING/ DAYTIME RUNNING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
SEDAN
THERMAL JOINT 2
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SWITCH
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER MOTOR
Go to component -> Ground distribution circuit, sedan (2 of 5) -> GRY WIRE
Wiring diagram gry (159 of 221)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COUPE
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT SEAT HEATER CONTROL UNIT
GRY WIRE
INNER TAILLIGHT
KEYLESS BUZZER
LEFT "C" PILLAR)
LEFT BACKUP LIGHT
LEFT BRAKE LIGHT
LEFT INNER TAILLIGHT
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LEFT REAR SEAT HEATER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
RIGHT BACKUP LIGHT
RIGHT BRAKE LIGHT
RIGHT INNER TAILLIGHT
RIGHT POWER MIRROR
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
RIGHT REAR SEAT HEATER SWITCH
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT
SEDAN
SEDAN, COUPE
TRUNK LID LATCH
TRUNK LID OUTER HANDLE SWITCH/ LICENSE PLATE LIGHT
WIRELESS CHARGER
Go to component -> Ground distribution circuit, sedan (5 of 5) -> GRY WIRE
Wiring diagram gry (160 of 221)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/RAIN SENSOR (TOP CENTER OF WINDSHIELD)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DRIVER'S JUNCTION (COUPE, SEDAN) DRIVER'S JUNCTION C
DRIVER'S JUNCTION A
EXCEPT HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
FUSE 18
FUSE 2-6
FUSE 22
GRN WIRE
GRY WIRE
HATCHBACK
HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
HIGH (LED)
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT HEADLIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LOW (LED)
LT BLU WIRE
OPTIONAL CONNECTOR (FOG LIGHT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
SEDAN
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
W/ CAN GATEWAY, HANDSFREE LINK
W/O AUTOMATIC WIPER W/ AUTOMATIC WIPER COUPE, SEDAN HATCHBACK
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit (2 of 2) -> GRY WIRE
