Honda Civic Type R X (2015-2021) driver's junction a Wiring diagrams
This page contains all the electrical diagrams for the component. driver's junction a, in which he is found in the car Honda Civic Type R X (2015-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's junction a (1 of 7)
ABS IND.
AUTO BRAKE HOLD MAIN (RED) IND WIRE
AUTO BRAKE HOLD MAIN IND
BLACK LIGHT LED DRIVER (W/ TFT)
BLK WIRE
BLU WIRE
BRAKE HOLD ACTIVE IND
BRAKE HOLD ACTIVE IND (RED) WIRE
BRAKE IND
BRAKE SYSTEM IND
BRN WIRE
CMBS OFF SWITCH
CMBS OFF/ RDM SWITCH
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER CIRCUIT
DIMMING STABILIZE CIRCUIT CIRCUIT
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
EXCEPT HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FAIL SAFE CIRCUIT
FORCED TURNING ON CIRCUIT
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
LT GRN WIRE
PNK WIRE
PPL
PRESS DOWN BRAKE IND 2 PEDAL/3 PEDAL
RED WIRE
SPEEDOMETER, MULTI-INFORMATION DISPLAY
TPMS IND
TPMS OFF SWITCH
VSA IND
VSA OFF IND
VSA OFF SWITCH
VSA/ TPMS OFF SWITCH
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM 5 PIN CONNECTOR 4 PIN CONNECTOR
WARNING DRIVER CIRCUIT
WHT WIRE
Go to component -> Anti-lock brakes circuit, hatchback (3 of 3) -> DRIVER'S JUNCTION A
Wiring diagram driver's junction a (2 of 7)
2.0L TURBO
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
B-CAN JUNCTION
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
DATA LINK CONNECTOR (DLC)
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
EXCEPT SPORT TOURING
FRONT SEAT HEATER CONTROL UNIT
FUSE 18
FUSE 7
GRN WIRE
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT
LT BLU WIRE
OPTION CONNECTOR (FOG LIGHT)
PNK WIRE
POWER WINDOW MASTER SWITCH
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SRS UNIT
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ CAN GATEWAY W/O CAN GATEWAY
W/ SPORT TOURING
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
WIRELESS CHARGER
YEL WIRE
Go to component -> Computer data lines circuit, hatchback (1 of 3) -> DRIVER'S JUNCTION A
Wiring diagram driver's junction a (3 of 7)
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/RAIN SENSOR (TOP CENTER OF WINDSHIELD)
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DRIVER'S JUNCTION (COUPE, SEDAN) DRIVER'S JUNCTION C
DRIVER'S JUNCTION A
EXCEPT HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
FUSE 18
FUSE 2-6
FUSE 22
GRN WIRE
GRY WIRE
HATCHBACK
HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
HIGH (LED)
HOT AT ALL TIMES
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT HEADLIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LOW (LED)
LT BLU WIRE
OPTIONAL CONNECTOR (FOG LIGHT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
SEDAN
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
W/ CAN GATEWAY, HANDSFREE LINK
W/O AUTOMATIC WIPER W/ AUTOMATIC WIPER COUPE, SEDAN HATCHBACK
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit (2 of 2) -> DRIVER'S JUNCTION A
Wiring diagram driver's junction a (4 of 7)
AUTO HIGH BEAM IND
AUTOMATIC BRAKE HOLD IND
AUTOMATIC BRAKE HOLD SYSTEM IND
BACK LIGHT LED DRIVER
BRN WIRE
CRUISE CONTROL IND
CRUISE CONTROL SYSTEM
CRUISE MAIN IND
DRIVER'S DOOR SWITCH
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
ECON MODE IND
EXCEPT HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
FLASH ROM
FOG LIGHT IND
FORCED TURNING OFF CIRCUIT
FROM DIMMING CIRCUIT
FROM SEAT BELT REMINDER IND (DIAGRAM 4 OF 4)
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT
GAUGE CONTROL MODULE
GDC (TFT)
GRN WIRE
HATCHBACK W/ HONDA SENSING, SPORT TOURING, TYPE-R
LEFT REAR DOOR SWITCH
LIGHTS ON IND
MULTI-INFORMATION DISPLAY
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
PPL
RAM
RED WIRE
SOUND SYSTEMS
SPEEDOMETER
TFT
TO AUTOMATIC BRAKE HOLD SYSTEM IND (DIAGRAM 4 OF 4)
TO ILLUMINATION ENCODER (DIAGRAM 1 OF 4)
WARNING DRIVING CIRCUIT
YEL WIRE
Go to component -> Instrument cluster circuit, hatchback (2 of 4) -> DRIVER'S JUNCTION A
Wiring diagram driver's junction a (5 of 7)
AUTO
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CLIMATE CONTROL PANEL
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DRIVER'S DOOR
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
FUSE 18
FUSE 20
FUSE 9
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR SEAT HEATER SWITCH
LOWER TRAY LIGHT
LT GRN WIRE
OFF PARK
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RED WIRE
RIGHT REAR SEAT HEATER SWITCH
TAILLIGHT RELAY
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY HOLDER A
UPPER TRAY LIGHT
VSA/TPMS OFF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Instrument illumination circuit, hatchback (1 of 3) -> DRIVER'S JUNCTION A
Wiring diagram driver's junction a (6 of 7)
2.0L
A/C COMPRESSOR CLUTCH RELAY
ALTERNATOR
AUDIO- NAVIGATION UNIT
AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
CENTER DISPLAY UNIT
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (DLC)
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
FOG LIGHT RELAY UNDER-HOOD FUSE/ RELAY HOLDER A
FROM FUSE 1-7 (DIAGRAM 1 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
FROM UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FUSE 18
FUSE 19
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 3-1
FUSE 3-2
FUSE 3-3
FUSE 3-4
FUSE 3-5
FUSE 3-6
GAUGE CONTROL MODULE
GRN WIRE
HORN RELAY
IMMOBILIZER KEYLESS CONTROL UNIT
INTERIOR LIGHTS CUT RELAY
LEFT "C" PILLAR)
LEFT REAR RELAY HOLDER A
LEFT REAR RELAY HOLDER B
LEFT REAR SEAT HEATER RELAY (HIGH)
LEFT REAR SEAT HEATER RELAY (LOW)
LT BLU WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
RADIATOR FAN RELAY
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY CIRCUIT BOARD
RIGHT REAR SEAT HEATER RELAY (HIGH)
RIGHT REAR SEAT HEATER RELAY (LOW)
STARTER CUT RELAY 1
TO FUSE 20 (DIAGRAM 1 OF 6)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 6)
UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
UNDER-HOOD RELAY HOLDER C UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
WIRELESS CHARGER
Go to component -> Power distribution circuit, hatchback (2 of 6) -> DRIVER'S JUNCTION A
Wiring diagram driver's junction a (7 of 7)
ADAPTIVE DAMPER CONTROL UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRN WIRE
CLIMATE CONTROL PANEL
CLIMATE CONTROL UNIT
CMBS OFF SWITCH/ RDM SWITCH
CONNECTOR
DIODE D
DRIVER'S JUNCTION A
DRIVER'S JUNCTION C
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FROM UNDER-DASH RELAY HOLDER (DIAGRAM 4 OF 6)
FRONT PASSENGER'S AIR BAG ON/OFF INDICATOR
FRONT SEAT HEATER CONTROL UNIT
FRONT SEAT HEATER RELAY
FUSE 11
FUSE 17
FUSE 21
FUSE 22
FUSE 3
FUSE 34
FUSE 35
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GAUGE CONTROL MODULE
IMMOBILIZER KEYLESS CONTROL UNIT
LEFT REAR SEAT HEATER SWITCH
LT BLU WIRE
MILLIMETER WAVE RADAR UNIT
MULTIPURPOSE CAMERA UNIT
NO. 2
OPTIONAL
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
PCM
PGM-FI MAIN RELAY 2
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
REAR WINDOW WIPER MOTOR
RED WIRE
RELAY CIRCUIT BOARD UNDER-HOOD FUSE/RELAY BOX
REVERSE RELAY
RFC UNIT
RIGHT REAR SEAT HEATER SWITCH
SHIFT POSITION INDICATOR
SRS UNIT
TO UNDER-DASH RELAY HOLDER (DIAGRAM 4 OF 6)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 4 OF 6)
TRANSMISSION CONTROL MODULE
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ ADAPTIVE DAMPER CONTROL
W/ EX, EXLN, LX,, SPORT
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
W/O ADAPTIVE DAMPER CONTROL
W/O EX, EXLN, LX,, SPORT
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
Go to component -> Power distribution circuit, hatchback (3 of 6) -> DRIVER'S JUNCTION A
