Instrument cluster circuit, hybrid for Honda Accord XI (2023-2024)

AUDIO REMOTE- HFL SWITCH AUTO HIGH-BEAM INDICATOR (GREEN) B-CAN TRANSCEIVER BB-CAN H BB-CAN L BEEPER BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE SYSTEM INDICATOR (RED) WIRE BRN WIRE CABLE REEL (ON STEERING COLUMN) COMPUTER DATA LINES SYSTEM DOOR, TRUNK LID OPEN INDICATOR DRIVE MODE SWITCH EPS INDICATOR EV SWITCH F-CAN TRANSCEIVER FUEL TANK UNIT FUSE 11 FUSE 9 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEAD-UP DISPLAY CIRCUIT HIGH BEAM INDICATOR HOT AT ALL TIMES HOT W/ IF-CAN H IF-CAN L IMMOBILIZER/ SECURITY INDICATOR INFOTAINMENT CONTROL UNIT JUNCTION BOX G KEYLESS ACCESS INDICATOR PARKING BRAKE REMINDER SEAT BELT REMINDER LEFT TURN SIGNAL INDICATOR LIGHTS ON INDICATOR LIGHTS ON REMINDER LOW OIL PRESSURE INDICATOR LT BLU WIRE LT GRN WIRE MALFUNCTION INDICATOR LAMP (MIL) PNK WIRE PPL PPL/RED WIRE RED WIRE RIGHT END OF DASH) RIGHT TURN SIGNAL INDICATOR SEAT BELT REMINDER INDICATOR SRS INDICATOR TAN WIRE TRANSMISSIONS SYSTEM UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WASHER FLUID LEVEL SWITCH WHT WIRE YEL WIRE

ACC COMBINATION SWITCH APPLY SWITCH AUTOMATIC BRAKE HOLD SWITCH BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR SWITCH DRIVER'S DOOR LATCH ELECTRIC PARKING BRAKE SWITCH ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH (BEHIND SHIFT SELECTOR) FUSE 4-1 FUSE 54 GRN WIRE GRY WIRE HOT AT ALL TIMES ILLUMINATION JUNCTION BOX B JUNCTION BOX I LT GRN WIRE PNK WIRE PPL RED WIRE RELEASE SWITCH SWITCH INDICATOR TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX VSA MODULATOR CONTROL UNIT WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOOR SWITCH ENGINE OIL PRESSURE SENSOR FRONT PASSENGER'S DOOR LATCH FUSE 24 GRY WIRE HOT AT ALL TIMES LEFT REAR DOOR LATCH LT BLU WIRE LT GRN WIRE PCM PPL/GRN WIRE PPL/GRY WIRE PPL/TAN WIRE RIGHT REAR DOOR LATCH TAN WIRE THERMAL JOINT 9 TRUNK LID LATCH TRUNK LID LATCH SWITCH TRUNK LIGHT UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE
