Computer data lines circuit, hybrid for Honda Accord XI (2023-2024)

AUTOMATIC LIGHTING CONTROL UNIT-SENSOR BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT DATA LINK CONNECTOR (DLC) EXCEPT HSPORT FUSE 13 FUSE 20 FUSE 9 GRY WIRE HEAD-UP DISPLAY HOT AT ALL TIMES HOT W/ HSPORT JUNCTION BOX G (LEFT END OF DASH) JUNCTION BOX J JUNCTION BOX J (IF EQUIPPED) (LEFT END OF DASH) LEFT HEADLIGHT LEFT SIDE BSI RADAR UNIT LT BLU WIRE PNK WIRE POWER SEAT CONTROL UNIT POWER WINDOW MASTER SWITCH PPL RED WIRE RELAY CONTROL MODULE RIGHT HEADLIGHT RIGHT SIDE BSI RADAR UNIT TAN WIRE THERMAL JOINT 14 THERMAL JOINT 15 THERMAL JOINT 7 THERMAL JOINT 8 UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX VENTILATED SEAT CONTROL UNIT/ FRONT SEAT HEATER CONTROL UNIT WHT WIRE YEL WIRE

AUDIO REMOTE- HFL SWITCH BLK WIRE BLU WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE CABLE REEL GAUGE CONTROL MODULE GRN WIRE GRY WIRE JUNCTION BOX C JUNCTION BOX H LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL/YEL WIRE RED WIRE TAN WIRE WHT WIRE YEL WIRE

ACOUSTIC VEHICLE ALERTING CONTROL UNIT ACTIVE NOISE CANCELLATION UNIT AUTOMATIC LIGHTING/ RAIN SENSOR BLU WIRE BRN WIRE CENTER DISPLAY UNIT EXCEPT HSPORT FRONT PASSENGER'S WEIGHT SENSOR (FRONT INNER SIDE) FRONT PASSENGER'S WEIGHT SENSOR (REAR INNER SIDE) GRN WIRE HSPORT INFOTAINMENT CONTROL UNIT JUNCTION BOX E (LEFT CENTER OF DASH) LT BLU WIRE LT GRN WIRE PNK WIRE PPL REAR OF ENGINE COMPT) RED WIRE SRS UNIT TAN WIRE TELEMATICS CONTROL UNIT WHT WIRE WINDSHIELD WIPER CONTROL UNIT/MOTOR WIRELESS CHARGER YEL WIRE

12 VOLT BATTERY SENSOR BLU WIRE BRN WIRE ELECTRIC A/C COMPRESSOR FRONT PASSENGER'S POWER WINDOW SWITCH GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE MILLIMETER WAVE RADAR MOONROOF MOTOR/ CONTROL UNIT MULTIPURPOSE CAMERA UNIT PARKING, BACKUP SENSOR CONTROL UNIT PNK WIRE PPL RED WIRE SHUTTER GRILLE TAN WIRE WHT WIRE YEL WIRE

BATTERY CONDITION MONITOR MODULE BLU WIRE BRN WIRE ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR EPS CONTROL UNIT GRN WIRE GRY WIRE JUNCTION BOX H (LEFT CENTER OF DASH) JUNCTION BOX K (LEFT SIDE OF DASH) JUNCTION BOX M (LEFT SIDE OF DASH) LT BLU WIRE LT GRN WIRE PCM PCU PNK WIRE PPL RED WIRE TAN WIRE VSA MODULATOR CONTROL UNIT WHT WIRE YEL WIRE
