1.5l turbo, transmission circuit for Honda Accord X facelift (2020-2023)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE CVT DRIVE PULLEY SPEED SENSOR CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE CVT DRIVEN PULLEY PRESSURE SENSOR CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE CVT SPEED SENSOR FUSE 10 FUSE 15 FUSE 39 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL RED WIRE SHIFT SOLENOID VALVE B SHIFT SOLENOID VALVE O/P TAN WIRE TOP OF TRANSMISSION) TORQUE CONVERTER TURBINE SPEED SENSOR TRANSMISSION CONTROL MODULE TRANSMISSION FLUID TEMPERATURE SENSOR UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BLU WIRE BRAKE LIGHT RELAY BRN WIRE DIODE A DIODE B FUSE 36 FUSE 37 FUSE 4 FUSE 42 FUSE 9 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ ACC RELAY ENERGIZED LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RELAY CIRCUIT BOARD RELAY ENERGIZED REVERSE RELAY SHIFT POSITION INDICATOR TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

APP SENSOR APP SENSOR A APP SENSOR B AUXILIARY TRANSMISSION FLUID PUMP AUXILIARY TRANSMISSION FLUID PUMP RELAY BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH BRN WIRE COMPUTER DATA LINES SYSTEM ECON/SPORT MODE/ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH F-CAN L F-CAN H F-CAN TRANSCEIVER FUSE 3 FUSE/RELAY HOLDER A GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT W/ DC-DC CONVERTER ENERGIZED LT BLU WIRE LT GRN WIRE PARK PIN SWITCH/SHIFT LOCK SOLENOID PCM (LEFT SIDE OF ENGINE COMPT) PNK WIRE PPL RED WIRE TAN WIRE TOP OF TRANSMISSION) WHT WIRE YEL WIRE

AUTOMATIC DIMMING INSIDE MIRROR/ HOMELINK REMOTE CONTROL BLK WIRE BLU WIRE BRN WIRE CABLE REEL COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE PADDLE SHIFTER + (UPSHIFT SWITCH) PADDLE SHIFTER - (DOWNSHIFT SWITCH) PNK WIRE POWER SEAT CONTROL UNIT PPL RED WIRE TAN WIRE TOP OF TRANSMISSION) TRANSMISSION RANGE SWITCH (IN TRANSMISSION) W/ AUTOMATIC DIMMING W/ MEMORY WHT WIRE YEL WIRE
