Honda Accord X (2017-2020) red Wiring diagrams

This page contains all the electrical diagrams for the component. red, in which he is found in the car Honda Accord X (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram red (111 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (111 of 206)

Get lifetime access to Honda Accord X (2017-2020)

BLK WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLU WIRE BRN WIRE CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM DRIVER'S AIR MIX CONTROL MOTOR EVAPORATOR TEMPERATURE SENSOR FUSE 3-5 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MODE CONTROL MOTOR PNK WIRE POWER TRANSISTOR PPL RECIRCULATION CONTROL MOTOR RED WIRE TAN WIRE THERMAL POINT 8 UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Automatic a/c circuit, except hybrid (1 of 5) -> RED WIRE

Wiring diagram red (112 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (112 of 206)

Get lifetime access to Honda Accord X (2017-2020)

B-CAN B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR ECON/SPORT MODE/ EV SWITCH ELECTRIC A/C COMPRESSOR (LOWER LEFT FRONT OF ENGINE) ELECTRIC HEATER COOLANT PUMP RELAY FUSE 12 FUSE 30 FUSE 42 FUSE 43 FUSE 5-1 GAUGE CONTROL MODULE GRN WIRE HOT AT ALL TIMES LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RELAY CIRCUIT BOARD RELAY ENERGIZED RFC RELAY SUB JUNCTION BOARD TAN WIRE THERMAL JOINT 1 UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Automatic a/c circuit, hybrid (3 of 4) -> RED WIRE

Wiring diagram red (113 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (113 of 206)

Get lifetime access to Honda Accord X (2017-2020)

2.0L TURBO A/T 2.0L TURBO M/T BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT INTERIOR LF ANTENNA FUSE 40 FUSE 5-5 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE PNK WIRE PPL REAR BUMPER LF ANTENNA REAR INTERIOR LF ANTENNA REAR SHELF LF ANTENNA RED WIRE SHIFT INTERLOCK SYSTEM TAN WIRE TRANSMISSION CONTROL MODULE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, except hybrid (1 of 6) -> RED WIRE

Wiring diagram red (114 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (114 of 206)

Get lifetime access to Honda Accord X (2017-2020)

ACC RELAY BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR OUTER HANDLE (W/ SMART ENTRY FUNCTION) FRONT PASSENGER'S DOOR OUTER HANDLE (W/ SMART ENTRY FUNCTION) FUSE 36 FUSE 5 FUSE 9 GRN WIRE GRY WIRE LF ANTENNA LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RELAY CIRCUIT BOARD TAN WIRE TOUCH SENSOR (LOCK) TOUCH SENSOR (UNLOCK) UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, except hybrid (2 of 6) -> RED WIRE

Wiring diagram red (115 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (115 of 206)

Get lifetime access to Honda Accord X (2017-2020)

2.0L TURBO BLK WIRE BLU WIRE BRN WIRE ENGINE START/STOP SWITCH FUSE 2-1 FUSE 2-5 FUSE 27 GRN WIRE GRY WIRE HOT AT ALL TIMES KEYLESS BUZZER LF ANTENNA LT BLU WIRE LT GRN WIRE PNK WIRE POWER SEAT CONTROL UNIT PPL RED WIRE SHIFT INTERLOCK SYSTEM TOP OF TRANSMISSION) UNDER-HOOD FUSE/RELAY BOX WHT WIRE WIRELESS CHARGER YEL WIRE

Go to component -> Power door locks circuit, except hybrid (3 of 6) -> RED WIRE

Wiring diagram red (116 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (116 of 206)

Get lifetime access to Honda Accord X (2017-2020)

BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL UNIT) DOOR LOCK KNOB DOOR LOCK SWITCH DOOR MULTIPLEX CONTROL UNIT DRIVER'S DOOR DRIVER'S DOOR LATCH DRIVER'S DOOR LOCK ACTUATOR DRIVER'S DOOR LOCK SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 53 FUSE 54 GRN WIRE GRY WIRE HOT AT ALL TIMES KEY KEY CYLINDER SWITCH LOCK LOCK KNOB SWITCH LT BLU WIRE LT GRN WIRE MOONROOF MOTOR/ CONTROL UNIT ORG/ WIRE PNK WIRE POWER WINDOW MASTER SWITCH PPL RED WIRE TAN WIRE UNDER-DASH FUSE/RELAY BOX UNLOCK WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, except hybrid (5 of 6) -> RED WIRE

Wiring diagram red (117 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (117 of 206)

Get lifetime access to Honda Accord X (2017-2020)

BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT INTERIOR LF ANTENNA FUSE 40 FUSE 5-5 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE PNK WIRE PPL REAR BUMPER LF ANTENNA REAR INTERIOR LF ANTENNA REAR SHELF LF ANTENNA RED WIRE RELAY CIRCUIT BOARD SHIFT INTERLOCK SYSTEM TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, hybrid (1 of 5) -> RED WIRE

Wiring diagram red (118 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (118 of 206)

Get lifetime access to Honda Accord X (2017-2020)

ACC RELAY BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SENSOR/LF ANTENNA FRONT PASSENGER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SENSOR/LF ANTENNA FUSE 36 FUSE 5 FUSE 9 GRN WIRE GRY WIRE LF ANTENNA LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE TAN WIRE TOUCH SENSOR (LOCK) TOUCH SENSOR (UNLOCK) UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, hybrid (2 of 5) -> RED WIRE

Wiring diagram red (119 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (119 of 206)

Get lifetime access to Honda Accord X (2017-2020)

ANTI-LOCK BRAKES SYSTEM B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 2-1 FUSE 2-5 FUSE 27 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES KEYLESS BUZZER LF ANTENNA LT GRN WIRE MULTI-INFORMATION DISPLAY (MID) PNK WIRE POWER SWITCH PPL RED WIRE SECURITY INDICATOR UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Power door locks circuit, hybrid (3 of 5) -> RED WIRE

Wiring diagram red (120 of 206)

Wiring diagram red for Honda Accord X (2017-2020) (120 of 206)

Get lifetime access to Honda Accord X (2017-2020)

AMBIENT LIGHT AUTO AUTO CLOSE OPEN AUTO AUTO OPEN CLOSE BLK WIRE BLU WIRE BODY CONTROL MODULE BRN WIRE CLOSE RELAY COMPUTER DATA LINES SYSTEM CONTROL UNIT) DOOR KEY CYLINDER SWITCH DOOR MULTIPLEX DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ DOOR SWITCH/ KEY CYLINDER SWITCH ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR EXCEPT HYBRID FRONT PASSENGER'S DOOR LATCH FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/DOOR SWITCH FUSE 17 GRN WIRE GRY WIRE HALL SENSOR HOT AT ALL TIMES INTERIOR LIGHT SWITCH KEY LOCK LT GRN WIRE MOONROOF MOTOR CONTROL UNIT (RIGHT FRONT OF ROOF) MOTOR OFF OPEN CLOSE OPEN RELAY ORG/ WIRE PNK WIRE POWER WINDOW MASTER SWITCH POWER WINDOWS SYSTEM PPL RED WIRE TAN WIRE TILT SWITCH UNDER-DASH FUSE/RELAY BOX UNLOCK WHT WIRE

Go to component -> Power top/sunroof circuit -> RED WIRE
