Honda Accord X (2017-2020) down switch Wiring diagrams
This page contains all the electrical diagrams for the component. down switch, in which he is found in the car Honda Accord X (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram down switch (1 of 3)
10 PIN CONNECTOR 8 PIN CONNECTOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DASHLIGHTS BRIGHTNESS CONTROL SWITCH (8 PIN CONNECTOR)
DASHLIGHTS BRIGHTNESS CONTROL/ HEAD-UP MAIN DISPLAY SWITCH
DASHLIGHTS BRIGHTNESS CONTROL/TRIP/ HEAD-UP MAIN DISPLAY SWITCH
DOWN SWITCH
ENCODER
EXCEPT HYBRID
FUSE 36
FUSE 48
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY
HOT AT ALL TIMES
HUD SWITCH
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
TAN WIRE
TRIP SWITCH
UNDER-DASH FUSE/RELAY BOX
UP SWITCH
YEL WIRE
Go to component -> Head-up display circuit -> DOWN SWITCH
Wiring diagram down switch (2 of 3)
10 PIN CONNECTOR 8 PIN CONNECTOR
2.0L TURBO
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DASHLIGHTS BRIGHTNESS CONTROL SWITCH
DASHLIGHTS BRIGHTNESS CONTROL/ HEAD-UP MAIN DISPLAY SWITCH
DOWN SWITCH
DRIVER'S DOOR LATCH SWITCH
ENCODER
ENGINE OIL PRESSURE SWITCH
FRONT PASSENGER'S DOOR LATCH SWITCH
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT (TOP OF FUEL TANK)
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY
HEAD-UP DISPLAY CIRCUIT
HUD SWITCH
LEFT REAR DOOR LATCH SWITCH
LT GRN WIRE
PCM (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
PPL/GRY WIRE
PPL/RED WIRE
RED WIRE
RIGHT REAR DOOR LATCH SWITCH
TAN WIRE
TRIP SWITCH
TRUNK LID LATCH SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, except hybrid (2 of 2) -> DOWN SWITCH
Wiring diagram down switch (3 of 3)
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DASHLIGHTS BRIGHTNESS CONTROL/TRIP/ HEAD-UP MAIN DISPLAY SWITCH
DOWN SWITCH
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ DOOR SWITCH/ KEY CYLINDER SWITCH
ENCODER
FRONT PASSENGER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ DOOR SWITCH
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT (TOP OF FUEL TANK)
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY
HEAD-UP DISPLAY CIRCUIT
HUD SWITCH
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH/ DOOR SWITCH
LT GRN WIRE
PCM
PPL/TAN WIRE
RED WIRE
RIGHT REAR DOOR LOCK ACTUATOR/KNOB SWITCH/ DOOR SWITCH
TAN WIRE
TRIP SWITCH
TRUNK LID LATCH SWITCH/ TRUNK LID RELEASE ACTUATOR
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UP SWITCH
W/ HEAD-UP DISPLAY W/O HEAD-UP DISPLAY
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit, hybrid (2 of 2) -> DOWN SWITCH
