3.5l, starting circuit for Honda Accord VIII facelift (2011-2013)
3.5l, starting circuit
A/T
BATTERY
BLK WIRE
CLUTCH INTERLOCK SWITCH (ON CLUTCH PEDAL SUPPORT)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
ELD UNIT
FUSE
HD IN
IGNITION SWITCH
INPUT
LOCK ON
LT BLU WIRE
LT GRN WIRE
M/T
MULTI- FUSE 1 BATTERY FUSE
MULTI- FUSE 3 IG MAIN FUSE
ORG/ WIRE
PL IN
REAR OF ENGINE COMPT)
STARTER
STARTER CUT RELAY
STARTER MOTOR
STARTER SOLENOID
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
UNDER- HOOD FUSE/ RELAY BOX (LEFT
W/ PADDLE SHIFTERS
W/O PADDLE SHIFTERS
WHT WIRE
YEL WIRE
