Honda Accord VIII facelift (2011-2013) steer- ing ignition key light lock assem- bly Wiring diagram

+B BACKUP +B BACKUP B-CAN HI B-CAN LO 13 35 33 VBU B-CAN HI B-CAN LO PNK COMPUTER DATA LINES SYSTEM WIRE 37 32 28 29 PG SG LOCK UNLOCK (UNDER LEFT SIDE OF DASH) 4 DOOR ANTENNA B-CAN HI B-CAN LO BLK WIRE BLU WIRE BRN WIRE CEILING LIGHT CENTER JUNCTION BOX CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CONTROL UNIT POWER WINDOW MASTER SWITCH CONTROL UNIT) COURTESY LAMPS CIRCUIT DOOR DOOR LOCK KNOB DOOR LOCK KNOB KEY DRIVER'S DOOR KEY CYLINDER SWITCH DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH DRIVER'S DOOR SWITCH DRIVER'S DOOR SWITCH (AT DRIVER'S "B" PILLAR) DRIVER'S JUNCTION BOX 1 DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL) DRIVER'S MICU DRIVER'S UNDER-DASH FUSE/RELAY BOX DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) FR DOOR SW L FR DOOR SW R FR DOOR SW R RR DOOR SW R FRONT INDIVIDUAL MAP LIGHTS FRONT PASSENGER'S DOOR SWITCH FUSE 15 FUSE 15 FUSE 16 FUSE 16 FUSE 5 GND (MICU -S) GND (MICU-P) GND (MICU-S) GND (MICU-S) GND (MICU-P) GND (MICU-P) GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY LIGHT IGNITION KEY SWITCH IMMOBILIZER KEYLESS CONTROL UNIT INTERIOR LIGHT SWITCH INTR LT- KEY KEY LT- KEY SW LEFT LEFT REAR DOOR SWITCH LEFT REAR DOOR SWITCH (4 DOOR) (AT LEFT "C" PILLAR) LOCK LT GRN WIRE MICU P-GND MICU S-GND MICU S-GND MICU P-GND MOONROOF SWITCH (IF EQUIPPED) OF TRUNK LID) OFF ON OFF DOOR ORG/ WIRE PASSENGER'S MICU PASSENGER'S UNDER-DASH FUSE/RELAY BOX PASSENGER'S MICU PASSENGER'S UNDER-DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE POWER WINDOW MASTER SWITCH RED WIRE RIGHT RIGHT REAR DOOR SWITCH RIGHT REAR DOOR SWITCH (4 DOOR) (AT RIGHT "C" PILLAR) RR DOOR SW L RR DOOR SW R STEER- ING IGNITION KEY LIGHT LOCK ASSEM- BLY STEER- ING LOCK ASSEM- BLY TRUNK LID LATCH SWITCH TRUNK LID OPENER SOLENOID/ LATCH SWITCH TRUNK LID OPENER SOLENOID/ LATCH SWITCH (MIDDLE REAR TRUNK LID LATCH SWITCH TRUNK LIGHT TRUNK SW TRUNK SW B-CAN LO B-CAN HI RR DOOR SW L FR DOOR SW L KEY LT- KEY SW UNDER-HOOD FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) UNLOCK VBU VBU ANTENNA VBU PNK B-CAN HI WIRE W/ MOONROOF WHT WIRE
