Honda Accord VIII facelift (2011-2013) scs wen f-can hi f-can lo Wiring diagram
This page shows the only wiring diagram for the component.scs wen f-can hi f-can lo, which is found in the car Honda Accord VIII facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram scs wen f-can hi f-can lo (1 of 1)
14 12 F-CAN HI F-CAN LO
2.4L
2.4L 3.5L
3.5L
3.5L A/T
7 1 11 K-LINE F-CAN HI F-CAN LO
ABS MODULATOR CONTROL UNIT
AUDIO UNIT
BLK WIRE
BRN WIRE
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT
DLC
DLC (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2
DRIVER'S JUNCTION BOX 2 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM
ENGINE MOUNT CONTROL UNIT
ENGINE MOUNT CONTROL UNIT (3.5L: A/T) (BEHIND LEFT KICK PANEL)
F-CAN HI
F-CAN LO
F-CAN LO F-CAN HI K-LINE WEN
FUSE 15
GAUGE CONTROL MODULE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 15
IMMOBILIZER KEYLESS CONTROL UNIT
K LINE
LT BLU WIRE
NAVIGATION UNIT
NAVIGATION UNIT (IF EQUIPPED) (UNDER RIGHT SIDE OF REAR SHELF)
NORMAL AUDIO
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PREMIUM AUDIO
RED WIRE
REMOTE STARTING CONTROL UNIT
REMOTE STARTING CONTROL UNIT (W/ HONDA ACCESSORY)
SCS
SCS WEN F-CAN HI F-CAN LO
SIDE OF DASH)
SRS UNIT
SRS UNIT (UNDER MIDDLE OF DASH)
TPMS CONTROL UNIT (IF EQUIPPED)
TPMS CONTROL UNIT (IF EQUIPPED) (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX
VSA ABS
VSA MODULATOR CONTROL UNIT
W/ HONDA ACCESSORY
WEN
WHT WIRE
YAW RATE-LATERAL ACCELERATION SENSOR
Go to component -> Data link connector circuit -> SCS WEN F-CAN HI F-CAN LO
