Honda Accord VIII facelift (2011-2013) right front impact sensor Wiring diagrams
This page contains all the electrical diagrams for the component. right front impact sensor, in which he is found in the car Honda Accord VIII facelift (2011-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front impact sensor (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CABLE REEL (IN STEERING COLUMN)
CAN HI
CAN LO
CAN LO CAN HI K-LINE
CENTER JUNCTION BOX
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DLC
DLC (UNDER LEFT SIDE OF DASH)
DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S AIR BAG SECOND INFLATOR
DRIVER'S JUNCTION BOX 1
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FAIL SAFE CIRCUIT
FAST CONTROL AREA NETWORK TRANSCEIVER
FRONT PASSENGER'S AIR BAG CUT-OFF
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S AIR BAG FIRST INFLATOR
FRONT PASSENGER'S AIR BAG FIRST INFLATOR (BEHIND LEFT SIDE OF GLOVE BOX)
FRONT PASSENGER'S AIR BAG SECOND INFLATOR
FRONT PASSENGER'S AIR BAG SECOND INFLATOR (BEHIND LEFT SIDE OF GLOVE BOX)
FUSE 11
FUSE 12
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HOT IN ON OR START
IGNITION
IGNITION IGNITION GND GND
INDICATOR
K LINE
LEFT FRONT IMPACT SENSOR
LEFT FRONT IMPACT SENSOR (BEHIND LEFT SIDE OF BUMPER)
LFS-
LFS- LFS+ RFS- RFS+
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PPL
PTT
RED WIRE
RFS-
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
SEAT BELT REMINDER INDICATOR
SIDE AIR BAG CUT-OFF INDICATOR
SRS INDICATOR
SRS UNIT
SRS UNIT (UNDER MIDDLE OF DASH)
STEERING WHEEL)
SYSTEM
WARNING DRIVE CIRCUIT
WEN
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, 2 door (1 of 3) -> RIGHT FRONT IMPACT SENSOR
Wiring diagram right front impact sensor (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CABLE REEL (IN STEERING COLUMN)
CAN HI
CAN LO
CAN LO CAN HI K-LINE
CENTER JUNCTION BOX
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DLC
DLC (UNDER LEFT SIDE OF DASH)
DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S AIR BAG SECOND INFLATOR
DRIVER'S JUNCTION BOX 1
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FAIL SAFE CIRCUIT
FAST CONTROL AREA NETWORK TRANSCEIVER
FRONT PASSENGER'S AIR BAG CUT-OFF
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S AIR BAG FIRST INFLATOR
FRONT PASSENGER'S AIR BAG FIRST INFLATOR (BEHIND LEFT SIDE OF GLOVE BOX)
FRONT PASSENGER'S AIR BAG SECOND INFLATOR
FRONT PASSENGER'S AIR BAG SECOND INFLATOR (BEHIND LEFT SIDE OF GLOVE BOX)
FUSE 11
FUSE 12
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
HOT IN ON OR START
IGNITION
IGNITION IGNITION GND GND
INDICATOR
K LINE
LEFT FRONT IMPACT SENSOR
LEFT FRONT IMPACT SENSOR (BEHIND LEFT SIDE OF BUMPER)
LFS-
LFS- LFS+ RFS- RFS+
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PPL
PTT
RED WIRE
RFS-
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT IMPACT SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
SEAT BELT REMINDER INDICATOR
SIDE AIR BAG CUT-OFF INDICATOR
SRS INDICATOR
SRS UNIT
SRS UNIT (UNDER MIDDLE OF DASH)
STEERING WHEEL)
SYSTEM
WARNING DRIVE CIRCUIT
WEN
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, 4 door (1 of 3) -> RIGHT FRONT IMPACT SENSOR
