Honda Accord VIII facelift (2011-2013) relay gnd b-can lo b-can high immo sig k-line Wiring diagrams
This page contains all the electrical diagrams for the component. relay gnd b-can lo b-can high immo sig k-line, in which he is found in the car Honda Accord VIII facelift (2011-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram relay gnd b-can lo b-can high immo sig k-line (1 of 2)
0=OFF 1=PARK 2=AUTO 3=HEAD
2.4L
3.5L
ANTENNA INPUT
ANTI-THEFT SYSTEM
B-CAN LO PNK B-CAN HIGH WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COMBINATION LIGHT SWITCH CONNECTOR
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM ANTI-THEFT SYSTEM COMPUTER DATA LINES SYSTEM
DAY
DRIVER'S JUNCTION BOX 1
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S UNDER- DASH FUSE/ RELAY BOX
FUSE
FUSE 15
FUSE 29
FUSE 31
FUSE 31 (HONDA ACCESSORY)
FUSE 5
FUSE 8
GND B+
GND VR+
GRY WIRE
HANDSFREE LINK CONNECTOR
HANDSFREE LINK SWITCH
HEADLIGHT SWITCH
HONDA ACCESSORY
HOT AT ALL TIMES
HOT AT ALL TIMES DRIVER'S UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
HOT IN ON OR START
IMMO SIG
INTERMITTENT DWELL TIME CONTROLLER
K LINE
LOW SMALL SW SW
LT BLU WIRE
LT GRN WIRE
METER
OFF SMALL SW SW
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY GND
RELAY GND B-CAN LO B-CAN HIGH IMMO SIG K-LINE
REMOTE STARTING CONTROL UNIT
REMOTE STARTING CONTROL UNIT GROUND
REMOTE STARTING CONTROL UNIT IN-LINE FUSE
REMOTE STARTING SYSTEM ANTENNA
SCS
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID (UNDER CENTER CONSOLE)
SMALL LOW SW SW
SMALL OFF SW SW
ST RLY COIL
STARTER CUT RELAY
VR+ GND
WHT WIRE
WIPER/WASHER SWITCH
WIPER/WASHER SWITCH CONNECTOR
YEL WIRE
Go to component -> 2.4l, remote starting circuit (1 of 2) -> RELAY GND B-CAN LO B-CAN HIGH IMMO SIG K-LINE
Wiring diagram relay gnd b-can lo b-can high immo sig k-line (2 of 2)
0=OFF 1=PARK 2=AUTO 3=HEAD
2.4L
3.5L
ANTENNA INPUT
ANTI-THEFT SYSTEM
B-CAN LO PNK B-CAN HIGH WIRE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COMBINATION LIGHT SWITCH CONNECTOR
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM ANTI-THEFT SYSTEM COMPUTER DATA LINES SYSTEM
DAY
DRIVER'S JUNCTION BOX 1
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S UNDER- DASH FUSE/ RELAY BOX
FUSE
FUSE 15
FUSE 29
FUSE 31
FUSE 31 (HONDA ACCESSORY)
FUSE 5
FUSE 8
GND B+
GND VR+
GRY WIRE
HANDSFREE LINK CONNECTOR
HANDSFREE LINK SWITCH
HEADLIGHT SWITCH
HONDA ACCESSORY
HOT AT ALL TIMES
HOT AT ALL TIMES DRIVER'S UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
HOT IN ON OR START
IMMO SIG
INTERMITTENT DWELL TIME CONTROLLER
K LINE
LOW SMALL SW SW
LT BLU WIRE
LT GRN WIRE
METER
OFF SMALL SW SW
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY GND
RELAY GND B-CAN LO B-CAN HIGH IMMO SIG K-LINE
REMOTE STARTING CONTROL UNIT
REMOTE STARTING CONTROL UNIT GROUND
REMOTE STARTING CONTROL UNIT IN-LINE FUSE
REMOTE STARTING SYSTEM ANTENNA
SCS
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID (UNDER CENTER CONSOLE)
SMALL LOW SW SW
SMALL OFF SW SW
ST RLY COIL
STARTER CUT RELAY
VR+ GND
WHT WIRE
WIPER/WASHER SWITCH
WIPER/WASHER SWITCH CONNECTOR
YEL WIRE
Go to component -> 3.5l, remote starting circuit (1 of 2) -> RELAY GND B-CAN LO B-CAN HIGH IMMO SIG K-LINE
