Honda Accord VIII facelift (2011-2013) park pin switch/ a/t gear position indicator panel light Wiring diagrams
This page contains all the electrical diagrams for the component. park pin switch/ a/t gear position indicator panel light, in which he is found in the car Honda Accord VIII facelift (2011-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram park pin switch/ a/t gear position indicator panel light (1 of 2)
ACC KEY LOCK
APP SENSOR
APP SENSOR (ON ACCELERATOR PEDAL SUPPORT)
APSA
APSA APSB
APSB
ATPP
BKSW
BKSW SLS PNK WIRE
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE PEDAL POSITION SWITCH
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 1
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S MICU KEY KEY LOCK SOL
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
FUSE 10
FUSE 17
FUSE 18
FUSE 5
GRN WIRE
HORN RELAY
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IG 1 METER
IGNITION KEY SWITCH
J/C
KEY INTERLOCK SOLENOID
KEY KEY LOCK SOL SW
LT GRN WIRE
ORG/ WIRE
P-PIN ATP-P SW
P-PIN ATP-P SW SW
PARK PIN SWITCH
PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT
PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT (UNDER CENTER CONSOLE)
PNK WIRE
POWER SEAT CONTROL UNIT
POWER SEAT CONTROL UNIT (W/ MEMORY)
PPL
RED WIRE
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID (UNDER CENTER CONSOLE)
SLS+
STEERING LOCK ASSEMBLY
STOP SW
TRANSMISSION RANGE SWITCH
TRANSMISSION RANGE SWITCH (ON REAR OF TRANSMISSION)
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
W/ MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 2.4l, shift interlock circuit -> PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT
Wiring diagram park pin switch/ a/t gear position indicator panel light (2 of 2)
ACC KEY LOCK
APP SENSOR
APP SENSOR (ON ACCELERATOR PEDAL SUPPORT)
APSA
APSA APSB
APSB
ATPP
BKSW
BKSW SLS PNK WIRE
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 1
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S MICU KEY KEY LOCK SOL
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
FUSE 10
FUSE 17
FUSE 18
FUSE 5
GRN WIRE
HORN RELAY
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IG 1 METER
IGNITION KEY SWITCH
KEY INTERLOCK SOLENOID
KEY KEY LOCK SOL SW
LT GRN WIRE
ORG/ WIRE
P-PIN ATP-P SW
P-PIN ATP-P SW SW
PARK PIN SWITCH
PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT
PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT (UNDER CENTER CONSOLE)
PNK WIRE
POWER SEAT CONTROL UNIT
POWER SEAT CONTROL UNIT (W/ MEMORY)
PPL
RED WIRE
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID (UNDER CENTER CONSOLE)
SLS+
STEERING LOCK ASSEMBLY
STOP SW
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
W/ MEMORY
W/ PADDLE SHIFTERS
W/O PADDLE SHIFTERS
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 3.5l, shift interlock circuit -> PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT
