Honda Accord VIII facelift (2011-2013) internal switch positions Wiring diagram
This page shows the only wiring diagram for the component.internal switch positions, which is found in the car Honda Accord VIII facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram internal switch positions (1 of 1)
B-CAN LO
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT
COM
COMPUTER DATA LINES SYSTEM
CONTROL UNIT B-CAN LO
CONTROL UNIT)
CONTROL VMP AS UNIT
DEFOGGER
DOWN
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 13
FUSE 16
GRN WIRE
GRY WIRE
HEAT (+)
HEAT ILLUMI PG SG
HOT AT ALL TIMES
HOT IN ON
ILLUMI HEAT SG PG
INTERNAL SWITCH POSITIONS
INTERNAL SWITCH POSITIONS SWITCH 1 UP DOWN LEFT RIGHT
L/R U/D
LEFT
LEFT POWER MIRROR
LEFT/RIGHT MOTOR
LR B-CAN HI
LR HEAT
LT BLU WIRE
LT GRN WIRE
MIRROR DIRECTION SELECTED
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
POWER WINDOWS SYSTEM
PPL
RED WIRE
RIGHT
RIGHT LEFT
RIGHT POWER MIRROR
SIDE OF DASH)
SWITCH 1
SWITCH 2
SWITCH 3
UART
UD LR UART B-CAN HI
UD UART
UP/DOWN MOTOR
VMP AS
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> INTERNAL SWITCH POSITIONS
