Honda Accord VIII facelift (2011-2013) hot at all times rear window fuse 14 defogger relay Wiring diagram

15 16 4 PPL AC-CLK AUDIO UNIT AUDIO-HVAC SUB-DISPLAY UNIT AUTOMATIC LIGHTING SENSOR/SUNLIGHT SENSOR (TOP MIDDLE OF DASH) B CAN B CAN HI LO B-CAN HI B-CAN LO GROUND BLK WIRE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH) BLOWER POWER TRANSISTOR (ON BOTTOM OF BLOWER UNIT) BLU WIRE BRN WIRE CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH) CLIMATE CONTROL UNIT CLIMATE CTRL SW COMMON POTENTIAL COMPUTER DATA LINES SYSTEM DISPLAY (CLK) DISPLAY (SI) A/C PRESSURE SENS DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL) DRIVER'S MICU ACS DUET CONT DUET RX DUET TX ENGINE CONTROLS SYSTEM EVAP TEMP SENS OUTSIDE AIR TEMP SENS SUNLIGHT SENS IN-CAR TEMP SENS FUSE 21 FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES REAR WINDOW FUSE 14 DEFOGGER RELAY HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) HOT IN ON DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) FUSE 16 IN-CAR TEMPERATURE SENSOR (RIGHT OF STEERING COLUMN) LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NORMAL AUDIO PREMIUM AUDIO OUTSIDE AIR TEMPERATURE SENSOR (BEHIND CENTER OF FRONT BUMPER) PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PGM-FI SUB- RELAY PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL PNK WIRE RED WIRE RED/YEL WIRE SC-SO SOUND SYSTEMS SUN LIGHT SENSOR W/ HANDS FREE LINK W/ MEMORY WHT WIRE YEL WIRE
