Honda Accord VIII facelift (2011-2013) handsfree link in line fuse Wiring diagram
This page shows the only wiring diagram for the component.handsfree link in line fuse, which is found in the car Honda Accord VIII facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram handsfree link in line fuse (1 of 1)
+B 12 13
+B HFT
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 IG 2 HFT HFT COM
15 16 17 18 GND
4 HANDSFREE LINK CONNECTOR
5 6 7 8 GND HFT HFT MUTE MIC -
AUDIO
AUDIO+ MIC SH MIC + MIC - +B HFT HBRAKE SW GND HFT
AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FUSE 16
FUSE 31
FUSE 31 FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
GAUGE CONTROL MODULE
GND HFT
GRY WIRE
HANDSFREE LINK CONNECTOR
HANDSFREE LINK GROUND
HANDSFREE LINK IN LINE FUSE
HANDSFREE LINK SWITCH
HANDSFREE- LINK CONTROL UNIT
HBRAKE SW
HFT COM
HFT MUTE
HOT AT ALL TIMES
HOT IN ON
IG 2 HFT
LT BLU WIRE
LT GRN WIRE
MIC + HFT COM AUDIO+ AUDIO-
MIC -
MIC SH
ORG/ WIRE
PARKING BRAKE SWITCH
PARKING BRAKE SWITCH (UNDER PARKING BRAKE LEVER)
PARKING BRAKE SWITCH CONNECTOR
RED WIRE
WHT WIRE
Go to component -> Hands free module circuit, honda accessory -> HANDSFREE LINK IN LINE FUSE
