Honda Accord VIII facelift (2011-2013) ga audio l+ ga audio r+ ga audio sh ga bus sh ga sys on ga b+ Wiring diagram
This page shows the only wiring diagram for the component.ga audio l+ ga audio r+ ga audio sh ga bus sh ga sys on ga b+, which is found in the car Honda Accord VIII facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ga audio l+ ga audio r+ ga audio sh ga bus sh ga sys on ga b+ (1 of 1)
AUDIO UNIT
BLK WIRE
DRIVER'S DOOR SPEAKER
FRONT PASSENGER'S DOOR SPEAKER
GA + B
GA AUDIO L+ GA AUDIO R+ GA AUDIO SH GA BUS SH GA SYS ON GA B+
GA AUDIO L-
GA AUDIO L- GA AUDIO R-
GA AUDIO R-
GA AUDIO SH
GA B+ GA SYS ON GA BUS SH GA AUDIO SH GANET AUDIO R+ GANET AUDIO L+
GA BUS+ GA BUS- GA GND
GA GND
GA GND GA BUS- GA BUS+
GA SYS ON
GA-BUS SH
GA-BUS-
GANET AUDIO L -
GANET AUDIO R -
GANET AUDIO R- GANET AUDIO L- USB VBUS USB DATA- USB DATA+ USB GND USB SH
GRN WIRE
GRY WIRE
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
NOT USED NOT USED
OF DASH)
PNK WIRE
RED WIRE
RIGHT TWEETER
USB ADAPTER CONNECTOR
USB ADAPTER UNIT
USB ADAPTER UNIT (UNDER CENTER CONSOLE)
USB DATA -
USB GND
USB PORT
USB SH
USB VBUS
WHT WIRE
Go to component -> Base radio circuit (3 of 3) -> GA AUDIO L+ GA AUDIO R+ GA AUDIO SH GA BUS SH GA SYS ON GA B+
