Heated seats circuit for Honda Accord VIII (2007-2011)
Heated seats circuit
4 DOOR
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
DRIVER'S SEAT HEATER (UNDER DRIVER'S SEAT)
DRIVER'S SEAT HEATER RELAY (HIGH) (UNDER DRIVER'S SEAT)
DRIVER'S SEAT HEATER RELAY (LOW) (UNDER DRIVER'S SEAT)
DRIVER'S SEAT HEATER SWITCH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FRONT PASSENGER'S SEAT HEATER (UNDER FRONT PASSENGER'S SEAT)
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE 16
FUSE 19
GRN WIRE
GRN/RED WIRE
GRY WIRE
HIGH INDICATOR
HOT AT ALL TIMES
HOT IN ON
LOW INDICATOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PPL
RED WIRE
SEAT BACK)
SEAT CUSHION)
SWITCH ILLUMINATION
WHT WIRE
