Car Wiring Diagrams for Rear camera circuit for Honda Accord VIII (2007-2011)

11 12 13 27 26 28 CAMERA SH CAMERA GND CAMERA RC GND RC VCC CAMERA ADPT BLK WIRE BLU WIRE BRN WIRE CAMERA CAMERA ADPT CAMERA GND CAMERA SH DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL) FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES NAVIGATION DISPLAY UNIT PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) RC GND RC VCC REARVIEW CAMERA REARVIEW CAMERA CONNECTOR (OPTION CONNECTOR) (BEHIND LEFT SIDE OF GLOVE BOX) RED WIRE UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE YEL WIRE
