Car Wiring Diagrams for Parking assistant circuit for Honda Accord VIII (2007-2011)

4 DOOR A/T A/T REVERSE RELAY BACKUP SENSOR BEEPER ASSEMBLY BACKUP SENSOR CONTROL UNIT BACKUP SENSOR IN LINE FUSE BACKUP SENSOR JUNCTION CONNECTOR BACKUP SENSOR SYSTEM CONNECTOR BEEFER - R MIDDLE SENS (+) L MIDDLE SENS (+) BLK WIRE BLU WIRE GRN WIRE GRN/WHT WIRE LEFT BACK-UP LIGHT LEFT BACKUP LIGHT CONNECTOR LEFT CORNER BACKUP SENSOR LEFT MIDDLE BACKUP SENSOR LEFT MIDDLE RIGHT MIDDLE BACKUP SENSOR BACKUP SENSOR LT BLU WIRE M/T NCA WIRE ORG/ WIRE R CORNER SENS (+) L CORNER SENS (+) POWER GROUND SENS (-) RED WIRE RIGHT CORNER BACKUP SENSOR RIGHT MIDDLE BACKUP SENSOR WHT/RED WIRE YEL/RED WIRE
