Car Wiring Diagrams for Hands free module circuit, except honda accessory for Honda Accord VIII (2007-2011)

7 6 5 4 3 2 1 +B PPL AUDIO REMOTE SWITCH AUDIO UNIT B CAN L B CAN H PNK WIRE BACK SWITCH BLK WIRE BLU WIRE BLUETOOTH TRANSCEIVER BRN WIRE CABLE REEL (B: IN STEERING COLUMN) (C: IN STEERING WHEEL) COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX 2 (BEHIND LEFT KICK PANEL) DRIVER'S UNDER-DASH FUSE/RELAY FUSE 18 BOX (BEHIND LEFT KICK PANEL) GRN WIRE GRN/RED WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (UNDER LEFT SIDE OF DASH) HFL MUTE HFL-VOICE CONTROL SWITCH STEERING WHEEL HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 15 HOT IN ACC OR ON LT BLU WIRE LT GRN WIRE MC + MC - GND MICROPHONE NAVI COMM 1 NAVI COMM 2 NAVI COMM 4 NAVI COMM 3 HFL COMM SH NAVIGATION UNIT (UNDER RIGHT SIDE OF REAR SHELF) OFF HOOK SWITCH ON HOOK SWITCH PPL PPL PPL RED WIRE SH ANCM F GND REMOTE SW GND TALK SWITCH TELM SIG + MIC SIG SH MIC + MIC - +B TELM SIG - TELM SIG SH HFL NAVI MIC + HFL NAVI MIC - TELM SIG SH TELM SIG - TELM SIG + HFL MUTE WHT WIRE YEL WIRE
