2.4l, backup lamps circuit, a/t for Honda Accord VIII (2007-2011)
2.4l, backup lamps circuit, a/t
A/T REVERSE DIODE A (UNDER LEFT SIDE OF DASH)
A/T REVERSE DIODE B (UNDER LEFT SIDE OF DASH)
A/T REVERSE RELAY
BLK WIRE
BRN WIRE
DRIVE INPUT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
FUSE 5
GRY WIRE
HOT IN ON OR START
J/C
LEFT BACK-UP LIGHT
LT BLU WIRE
RED WIRE
RIGHT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (ON REAR OF TRANSMISSION)
WHT WIRE
