Data link connector circuit for Honda Accord VIII (2007-2011)
Data link connector circuit
14 12 F-CAN HI F-CAN LO
2.4L
2.4L 3.5L
3.5L
7 1 11 K-LINE F-CAN HI F-CAN LO
AUDIO UNIT
BLK WIRE
BRN WIRE
CENTER JUNCTION BOX (UNDER LEFT
DLC (UNDER LEFT SIDE OF DASH)
DRIVER'S JUNCTION BOX 2
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ENGINE MOUNT CONTROL UNIT (3.5L: A/T) (BEHIND LEFT KICK PANEL)
F-CAN HI
F-CAN LO
F-CAN LO F-CAN HI K-LINE WEN
GAUGE CONTROL MODULE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) FUSE 15
IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN)
K LINE
LT BLU WIRE
NAVIGATION UNIT (UNDER RIGHT SIDE OF REAR SHELF)
NORMAL AUDIO
ORG/ WIRE
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PREMIUM AUDIO
RED WIRE
SCS WEN F-CAN HI F-CAN LO
SIDE OF DASH)
SRS UNIT (UNDER MIDDLE OF DASH)
TPMS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
VSA ABS
WEN
WHT WIRE
YAW RATE- LATERAL ACCELERATION SENSOR (2.4L: VSA; 3.5L) (UNDER CENTER CONSOLE)
YEL WIRE
