Honda Accord VIII (2007-2011) network controller Wiring diagrams
This page contains all the electrical diagrams for the component. network controller, in which he is found in the car Honda Accord VIII (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram network controller (1 of 4)
+B BACK UP
AUTO LT SID
AUTO LT SIG
AUTO LT SIP
AUTOMATIC LIGHTING SENSOR
AUTOMATIC LIGHTING SENSOR/ SUNLIGHT SENSOR (TOP MIDDLE OF DASH)
B-CAN HI
B-CAN LO
BACK-UP
BACK-UP H/L
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FOG LIGHT CONTROL CIRCUIT
FOG LIGHT INDICATOR
FOG LIGHT SWITCH
FR FOG SW
FUSE 15
FUSE 26
FUSE 3
FUSE 5
FUSE FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LEFT FOG LIGHT
LIGHTING
MICU-P
MICU-S
NAVIGATION SYSTEM
NETWORK CONTROLLER
PASSENGER'S MICU
PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
PNK WIRE
PPL
RED WIRE
RIGHT FOG LIGHT
UNDER- HOOD
W/ NAVIGATION
WARNING DRIVE CIRCUIT
WHT WIRE
Go to component -> Fog lamp circuit, with autolamps -> NETWORK CONTROLLER
Wiring diagram network controller (2 of 4)
+B BACK UP
B-CAN HI
B-CAN LO
BACK-UP
BACK-UP H/L
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FOG LIGHT INDICATOR
FOG LIGHT RELAY
FOG LIGHT SWITCH
FR FOG RLY CL-
FR FOG SW
FUSE 15
FUSE 26
FUSE 3
FUSE 5
FUSE FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT)
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LEFT FOG LIGHT
LIGHTING
MICU-P
MICU-S
NAVIGATION SYSTEM
NETWORK CONTROLLER
PANEL)
PASSENGER'S MICU
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (BEHIND RIGHT KICK
PNK WIRE
PPL
RED WIRE
RIGHT FOG LIGHT
UNDER- HOOD
USA
W/ NAVIGATION
WARNING DRIVE CIRCUIT
WHT WIRE
Go to component -> Fog lamp circuit, without autolamps -> NETWORK CONTROLLER
Wiring diagram network controller (3 of 4)
+B BACK UP
AUTO LT SID
AUTO LT SIG
AUTO LT SIP
AUTOMATIC LIGHTING SENSOR
B-CAN HI
B-CAN LO
BACK-UP H/L
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRN WIRE
CIRCUIT
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
COMPUTER PARKING BRAKE SWITCH (UNDER PARKING BRAKE LEVER) DATA LINES SYSTEM
DIMMER SW
DIMMER/ FLASH- TO-PASS SWITCH 0) LOW 1) HIGH 2) PASSING
DRIVER'S DOOR SWITCH (AT DRIVER'S "B" PILLAR)
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
DRL INDICATOR
FR DOOR SW L
FUSE 1
FUSE 15
FUSE 28
FUSE 30
FUSE 4
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
H/L LOW SW
H/L OFF SW
HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD
HIGH BEAM CONTROL CIRCUIT
HIGH BEAM DIMMING CIRCUIT
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
IGNITION KEY SWITCH/ IGNITION KEY SWITCH KEY LIGHT
INDICATOR DIMMING CIRCUIT
KEY SW
LEFT HEADLIGHT
LIGHTING
LIGHTS ON INDICATOR
LOW BEAM CONTROL CIRCUIT
LT BLU WIRE
LT GRN WIRE
MICU-P
MICU-S
NAVIGATION SYSTEM
NETWORK CONTROLLER
ORG/ WIRE
PASSENGER'S REAR OF ENGINE COMPT) MICU
PASSING SW
PNK WIRE
RED WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
SMALL SW
UNDER- HOOD FUSE/ RELAY BOX (LEFT
W/ NAVIGATION
WARNING DRIVE CIRCUIT
WHT WIRE
WHT/RED WIRE
Go to component -> Headlamps circuit -> NETWORK CONTROLLER
Wiring diagram network controller (4 of 4)
2.4L
2.4L 3.5L
3 4 B-CAN LO B-CAN HI K-LINE S-NET LG PNK WIRE
3.5L
3.5L 2.4L
AREA NETWORK
B-CAN HI
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BODY
BRN WIRE
BRN/YEL WIRE
CIRCUIT
COMPUTER CAN-H CAN-L RLY CTRL RLY CTRL GND S-NET DATA LINES SYSTEM
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROLLER
DLC (UNDER LEFT SIDE OF DASH)
DRIVE
DRIVER'S
DRIVER'S +B BACK- MICU UP
DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
DRIVER'S MICU B-CAN LO
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS SYSTEM
ETCS CONTROL RELAY
FAST
FUEL PUMP PNK WIRE
FUEL PUMP RELAY
FUEL TANK UNIT (TOP OF FUEL TANK)
FUSE 15
FUSE 17
FUSE 9 FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY SWITCH
IGNITION KEY SWITCH/KEY LIGHT
IMMOBILIZER KEYLESS CONTROL UNIT (IN STEERING COLUMN)
IMMOBILIZER SYSTEM INDICATOR
KEY SW
LT BLU WIRE
LT GRN WIRE
NETWORK CONTROLLER
NOT (UNDER LEFT USED SIDE OF DASH)
NOT USED
PARKING BRAKE SWITCH (UNDER PARKING BRAKE LEVER)
PGM-FI MAIN RELAY
PGMETCS
PNK SYSTEM WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
S-NET
TRANSCEIVER/
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VBU
W/ NOT NAVIGATION USED DRIVER'S JUNCTION BOX 1 (BEHIND LEFT KICK PANEL)
WARNING
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Immobilizer circuit -> NETWORK CONTROLLER
