Honda Accord VIII (2007-2011) drive input Wiring diagrams
This page contains all the electrical diagrams for the component. drive input, in which he is found in the car Honda Accord VIII (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
drive input wiring diagram (1 of 2)
A/T REVERSE DIODE A (UNDER LEFT SIDE OF DASH)
A/T REVERSE DIODE B (UNDER LEFT SIDE OF DASH)
A/T REVERSE RELAY
BLK WIRE
BRN WIRE
DRIVE INPUT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
FUSE 5
GRY WIRE
HOT IN ON OR START
J/C
LEFT BACK-UP LIGHT
LT BLU WIRE
RED WIRE
RIGHT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (ON REAR OF TRANSMISSION)
WHT WIRE
Go to component -> 2.4l, backup lamps circuit, a/t -> DRIVE INPUT
drive input wiring diagram (2 of 2)
A/T REVERSE DIODE A (UNDER LEFT SIDE OF DASH)
A/T REVERSE DIODE B (UNDER LEFT SIDE OF DASH)
A/T REVERSE RELAY
BLK WIRE
BRN WIRE
DRIVE INPUT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ECM/PCM (LEFT FRONT OF ENGINE COMPT)
FUSE 5
GRY WIRE
HOT IN ON OR START
J/C
LEFT BACK-UP LIGHT
LT BLU WIRE
RED WIRE
RIGHT BACK-UP LIGHT
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
WHT WIRE
Go to component -> 3.5l, backup lamps circuit, a/t -> DRIVE INPUT
