3.0l, base radio circuit, except hybrid without rear entertainment for Honda Accord VII facelift (2005-2008)

1 3 XM RECEIVER AM SIGNAL INPUT ANTENNA ANTENNA LEAD CONNECTOR ANTENNA LEAD JACK AUDIO UNIT BLK WIRE BLU WIRE BLU/BLK (OR PNK) WIRE BLU/RED WIRE BLU/WHT (OR BLU) WIRE BLU/YEL (OR PPL) WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DEFOGGER SYSTEM DISPLAY MODULE FM SIG WINDOW ANTENNA FM SIGNAL INPUT FREQUENCY MODULATOR UNIT (UNDER CENTER OF DASH) FUSE 32 FUSE 33 FUSE 5 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON LT BLU WIRE LT GRN WIRE MICU NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK (OR LT GRN) WIRE PNK WIRE POWER INPUT ANTENNA OUTPUT PPL PPL PNK WIRE RADIO SW REAR WINDOW AM SIG WINDOW ANTENNA RED WIRE RED/BLK WIRE RED/BLU WIRE SUB-ANTENNA LEAD UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-DASH FUSE/RELAY BOX CONNECTOR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WINDOW ANTENNA COIL (AT LEFT "C" PILLAR) XM SATELLITE IN-LINE FUSE 1 XM SATELLITE IN-LINE FUSE 2 YEL WIRE YEL/GRN WIRE YEL/RED WIRE

BLK/RED WIRE BLU WIRE BLU/BLK (OR PNK) WIRE BLU/ORG WIRE BLU/WHT (OR BLU) WIRE BLU/YEL (OR PPL) WIRE BRN WIRE CABLE REEL CHANNEL DOWN SWITCH CHANNEL UP SWITCH CROSSOVER NETWORK UNIT DRIVER'S DOOR SPEAKER EXCEPT EX-L: NAVIGATION FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRN/BLK (OR RED/BLU) WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL (OR RED/BLU) WIRE GRN/YEL WIRE GRY (OR RED) WIRE GRY WIRE GRY/BLU WIRE HANDS-FREE TELEPHONE CONTROL UNIT LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE MODE SWITCH PNK (OR LT GRN) WIRE PNK/BLU WIRE RADIO REMOTE SWITCH RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT REAR SPEAKER RIGHT TWEETER STEERING WHEEL) VOLUME DOWN SWITCH VOLUME UP SWITCH YEL WIRE YEL/GRN WIRE
