Power distribution circuit, except hybrid for Honda Accord VII facelift (2005-2008)

2.4L 2.4L: EX 2.4L: EX-L, 3.0L : LX, CANADA SE, EX-L 3.0L A/C COMPRESSOR CLUTCH RELAY A/C CONDENSER FAN RELAY A/F SENSOR RELAY MICU ABS MODULATOR CONTROL UNIT (2.4L) VSA MODULATOR CONTROL UNIT (3.0L) ALTERNATOR BATTERY BLK WIRE BLOWER MOTOR RELAY BLU WIRE BOX (ON LEFT REAR CORNER OF ENGINE COMPT, FORWARD OF STRUT TOWER) BRAKE PEDAL POSITION SWITCH IGNITION KEY SWITCH/ KEY LIGHT HAZARD WARNING SWITCH DLC DRIVER'S POWER SEAT ADJUSTMENT SWITCH DRL RELAY DRL CONTROL UNIT ELECTRICAL LOAD DETECTOR (ELD) UNIT FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH (SEDAN 3.0L: EX-L) FUSE 1 FUSE 10 (NOT USED) FUSE 11 (2.4L) (3.0L) FUSE 12 FUSE 12 FUSE 2 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 20 FUSE 21 FUSE 4 FUSE 3 FUSE 8 FUSE 9 FUSE 19 GRN WIRE HORN RELAY RELAY CONTROL MODULE IGNITION COIL RELAY MULTI- FUSE 22 PGM-FI MAIN RELAY 1 RADIATOR FAN RELAY REAR WINDOW DEFOGGER RELAY RED WIRE SEAT HEATER RELAY (EX-L) STARTER STARTER SOLENOID THROTTLE ACTUATOR CONTROL MODULE RELAY TO FUSE 15 (DIAGRAM 3 OF 4) TO MULTI-FUSE 23 (DIAGRAM 2 OF 4) TURN SIGNAL/ HAZARD RELAY UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY USA CANADA WHT (OR BLK/YEL) WIRE WHT WIRE

A/T: 2.4L A/T: 3.0L BLK WIRE BLU WIRE CLUTCH INTERLOCK SWITCH COUPE ECM/PCM (2.4L) WINDSHIELD WASHER MOTOR ECM/PCM (3.0L) EX-L: W/ NAVIGATION FROM ELD UNIT (DIAGRAM 1 OF 4) FUSE 10 FUSE 11 FUSE 19 FUSE 20 FUSE 22 FUSE 31 FUSE 27 FUSE 28 FUSE 29 FUSE 32 FUSE 33 GRN WIRE GRY WIRE IGNITION SWITCH IMMOBILIZER CONTROL UNIT- RECEIVER WINDSHIELD WIPER MOTOR JUNCTION CONNECTOR LT GRN WIRE M/T MICU MOONROOF CLOSE RELAY MOONROOF OPEN RELAY MULTI- FUSE 23 NAVIGATION UNIT MOONROOF CONTROL UNIT NOT USED NOT USED ON LOCK OFF OPDS UNIT SRS UNIT PGM-FI MAIN RELAY 2 POWER WINDOW MASTER SWITCH POWER WINDOW RELAY RED WIRE SEDAN SRS UNIT STARTER STARTER CUT RELAY STARTER SOLENOID TO ACCESSORY POWER SOCKET RELAY (DIAGRAM 4 OF 4) TO FUSE 18 (DIAGRAM 4 OF 4) TO FUSE 30 (DIAGRAM 3 OF 4) TRANSMISSION RANGE SWITCH TRANSMISSION RANGE SWITCH AUDIO UNIT NAVIGATION DISPLAY UNIT UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) WHT WIRE YEL WIRE

1 5 (SEDAN) (COUPE) 2.4L 3.0L A/C COMPRESSOR CLUTCH RELAY AUDIO UNIT XM RECEIVER AUDIO- HVAC DISPLAY MODULE CLIMATE CONTROL UNIT AUDIO-HVAC DISPLAY MODULE AUTOMATIC A/C MANUAL A/C BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLU WIRE CANADA CEILING LIGHT AMBIENT LIGHT (EX, EX-L) COMBINATION SWITCH CONTROL UNIT CONDENSER FAN RELAY CONTROL BLOCK CORNER OF ENGINE COMPT, FORWARD OF STRUT TOWER) DRIVER'S DOOR COURTESY LIGHT DRIVER'S VANITY MIRROR LIGHT EX-L FAN CONTROL RELAY (3.0L) FROM ELD UNIT (DIAGRAM 1 OF 4) FROM IGNITION SWITCH (DIAGRAM 2 OF 4) FRONT PASSENGER'S DOOR COURTESY LIGHT FRONT PASSENGER'S VANITY MIRROR INDIVIDUAL MAP LIGHTS FUSE 15 FUSE 2 FUSE 30 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 GAUGE CONTROL MODULE IMMOBILIZER CONTROL UNIT- RECEIVER GRN WIRE HIGH BEAM HEADLIGHT RELAY JUNCTION CONNECTOR LOW BEAM HEADLIGHT RELAY MICU NAVIGATION DISPLAY UNIT (EX-L, IF EQUIPPED) NAVIGATION UNIT (EX-L, IF EQUIPPED) POWER MIRROR SWITCH POWER WINDOW MASTER SWITCH RADIATOR FAN RELAY REAR WINDOW DEFOGGER RELAY RECIRCULATION CONTROL MOTOR RED WIRE RELAY CONTROL MODULE SEAT HEATER RELAY TAILLIGHT RELAY TO ACCESSORY POWER SOCKET RELAY (DIAGRAM 4 OF 4) TRUNK LIGHT UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (ON LEFT REAR WHT WIRE WIPER/WASHER SWITCH YEL WIRE

2.4L 3 OF 4) 3.0L ABS MODULATOR CONTROL UNIT ACCESSORY ACCESSORY POWER SOCKET RELAY ALTERNATOR ALTERNATOR MAF/IAT SENSOR BLK WIRE BRAKE PEDAL POSITION SWITCH (3.0L) CIGARETTE LIGHTER CMP SENSOR A COMBINATION SWITCH CONTROL UNIT CONTROL BLOCK DOOR MULTIPLEX CONTROL UNIT DRL CONTROL UNIT ECM/PCM ELD UNIT ENGINE MOUNT CONTROL SOLENOID VALVE (A/T) ENGINE MOUNT CONTROL SOLENOID VALVE EVAP CANISTER PURGE VALVE EVAP CANISTER PURGE VALVE FACTORY FROM FUSE 32 (DIAGRAM 2 OF 4) FROM FUSE 6 (DIAGRAM FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 4) FRONT ACCESSORY POWER SOCKET FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR FRONT PASSENGER'S POWER WINDOW SWITCH (EX, EX-L) FUSE 18 FUSE 21 FUSE 9 GAUGE CONTROL MODULE BACKUP LIGHT SWITCH HAZARD WARNING SWITCH JUNCTION JUNCTION CONNECTOR MICU POWER WINDOW MASTER SWITCH REAR ACCESSORY POWER SOCKET (EXCEPT DX) RED WIRE RELAY CONTROL MODULE REVERSE LOCKOUT SOLENOID (COUPE, M/T) SECONDARY SHIFT LOCK SOLENOID (A/T) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VSA MODULATOR CONTROL UNIT WHT WIRE WHT/RED WIRE WIPER/ WASHER SWITCH YEL WIRE
