Instrument illumination circuit, hybrid for Honda Accord VII facelift (2005-2008)

Instrument illumination circuit, hybrid (1 of 2)

Accord Honda VII facelift (2005-2008): Instrument illumination circuit, hybrid (1 of 2)

Get access

BLK WIRE BLK/RED WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE COMBINATION LIGHT SWITCH COMBINATION SWITCH CONTROL UNIT CONTROL BLOCK CONTROLLER AREA NETWORK CONTROLLER ENCODER SWITCH FUSE 21 FUSE 3 FUSE 4 FUSE 7 GAUGE CONTROL MODULE HEADLIGHT SWITCH 0) OFF 1) PARK 2) HEAD HOT AT ALL TIMES HOT IN ON OR START J/C LT GRN WIRE MICU RED WIRE RED/BLK WIRE TAILLIGHT RELAY TRIP/RESET SWITCH UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-HOOD FUSE RELAY BOX (AT LEFT SIDE OF ENGINE COMPT) WHT WIRE WIPER/ WASHER SWITCH YEL WIRE

Instrument illumination circuit, hybrid (2 of 2)

Accord Honda VII facelift (2005-2008): Instrument illumination circuit, hybrid (2 of 2)

Get access

AMBIENT LIGHT AUDIO REMOTE SWITCH AUDIO UNIT BLK WIRE CABLE REEL CIGARETTE LIGHTER LIGHT CRUISE CONTROL COMBINATION SWITCH DRIVER'S SEAT HEATER SWITCH FRONT ASHTRAY LIGHT FRONT PASSENGER'S SEAT HEATER SWITCH GLOVE BOX LIGHT GRN WIRE HAZARD WARNING SWITCH J/C MOONROOF SWITCH NAVIGATION UNIT (IF EQUIPPED) PARK PIN SWITCH/ A/T GEAR POSITION CONSOLE LIGHT RED WIRE RED/BLK WIRE UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VOICE CONTROL SWITCH (USA NAVIGATION) VSA OFF SWITCH
