Fog lamp circuit for Honda Accord VII facelift (2005-2008)
Fog lamp circuit
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
COMPARTMENT)
COMPUTER DATA LINES SYSTEM
CONTROL BLOCK
FOG LIGHT RELAY 2 (AT LEFT SIDE OF ENGINE
FOG LIGHT SWITCH
FUSE 10
FUSE 7
GRN WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT WITH HEADLIGHT SWITCH IN HEAD OR PARK
LEFT FOG LIGHT
OFF
ON IND.
RED WIRE
RED/BLK WIRE
RELAY CONTROL MODULE
RIGHT FOG LIGHT
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
