Back-up lamps circuit, a/t except hybrid for Honda Accord VII facelift (2005-2008)
Back-up lamps circuit, a/t except hybrid
1 2 (COUPE) (SEDAN)
1 2 (SEDAN) (COUPE)
10 6 (2.4L) (3.0L)
2.4L
3.0L
ATPR BACK LT
BACK LT-
BLK WIRE
COUPE
COUPE, SEDAN
ENGINE CONTROLS SYSTEM
FUSE 21
GRN WIRE
HOT IN ON OR START
IGNITION
LEFT BACK-UP LIGHT
MICU
NAVIGATION UNIT
OPTIONAL CONNECTOR (EX, EX-L 3.0L: LX)
REAR JUNCTION BLOCK
RED WIRE
RIGHT BACK-UP LIGHT
SEDAN
SEDAN, COUPE
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
W/ NAVIGATION
WHT WIRE
WHT/GRN WIRE
