3.0l, computer data lines circuit, except hybrid for Honda Accord VII facelift (2005-2008)
3.0l, computer data lines circuit, except hybrid
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
CONNECTOR (EX-L: IN TRUNK, UNDER RIGHT SIDE OF REAR SHELF)
DATA LINK CONNECTOR (DLC)
DIAG
DIAG K
DLC
ECM/PCM (UNDER MIDDLE OF DASH)
FUSE 8
GAUGE CONTROL MODULE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
IMMOBILIZER CONTROL UNIT -RECEIVER (IN STEERING COLUMN COVER)
JUNCTION
JUNCTION CONNECTOR
K LINE
LT GRN/BLK WIRE
MES
MES CONNECTOR (BEHIND LEFT KICK PANEL)
MICU
MULTIPLEX CONTROL INSPECTION CONNECTOR
NAVIGATION SERVICE CHECK
NAVIGATION UNIT (EX-L) (IN TRUNK, UNDER MIDDLE OF REAR SHELF)
RED WIRE
RED/WHT WIRE
SCS
SRS UNIT (UNDER MIDDLE OF DASH)
VSA MODULATOR CONTROL UNIT (RIGHT FRONT OF ENGINE COMP)
WEN
WHT WIRE
WHT/GRN WIRE
