Honda Accord VII facelift (2005-2008) sensor output Wiring diagrams
This page contains all the electrical diagrams for the component. sensor output, in which he is found in the car Honda Accord VII facelift (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sensor output (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 DBW M+ IG
APP SENSOR (RIGHT SIDE OF ENGINE COMP)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE PDL SW
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN/BLK WIRE
BRN/YEL WIRE
CABLE REEL
CAN-HIGH CAN-LOW
CLUTCH PEDAL POSITION SWITCH (M/T) (UNDER LEFT SIDE OF DASH)
CONTROL BLOCK
CRUISE CONTROL COMBINATION SWITCH STEERING WHEEL
CRUISE CONTROL INDICATOR
CRUISE CONTROL MAIN SWITCH INDICATOR
DBW M- SG
DIMMING CIRCUIT CRIUSE CONTROL
ENGINE CONTROLS SYSTEM
FUSE 1
FUSE 13
FUSE 18
FUSE 7
GAUGE CONTROL MODULE
GAUGES/ INDICATORS
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION
JUNCTION CONNECTOR
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAIN SWITCH
MRLY DBWRLY BRAKE PDL SW
NETWORK TRANSCEIVER FAST CONTROLLER AREA
OF DASH)
OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR (ON TRANSMISSION HOUSING)
PGM-FI MAIN RELAY 1
PNK WIRE
POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY CONTROL MODULE HORN RELAY
SEDF
SEFD
SENSOR OUTPUT
SET SWITCH CANCEL SWITCH RESUME SWITCH
THROTTLE ACTUATOR CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
THROTTLE ACTUATOR CONTROL MODULE RELAY (3.0L: BEHIND LEFT SIDE OF GLOVE BOX)
TP SENSOR/THROTTLE ACTUATOR (ON THROTTLE BODY)
TRANSMISSION RANGE SWITCH (A/T) (ON TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY FUSE 21 BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
VCC
WARNING DRIVE CIRCUIT
WHT RED/ WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL GRN/ WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> 3.0l, cruise control circuit, except hybrid -> SENSOR OUTPUT
Wiring diagram sensor output (2 of 2)
1 2 3 4 5 6 7 8 DBW M+ IG
AREA NETWORK CONTROLLER
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE PDL SW DBWRLY
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRN/BLK WIRE
CABLE REEL
CAN-HIGH CAN-LOW
CONTROL BLOCK
CRUISE CONTROL COMBINATION SWITCH STEERING WHEEL
CRUISE CONTROL DIMMING CIRCUIT A/T GEAR POSITION INDICATOR/
CRUISE CONTROL INDICATOR
CRUISE CONTROL MAIN SWITCH INDICATOR
DRIVE CIRCUIT
DRIVE INPUT SENSOR INPUT SEDF SEFD
FUSE 1
FUSE 13
FUSE 18
FUSE 7
GAUGE CONTROL MODULE
GAUGES/ INDICATORS
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
IDLE STOP SWITCH (UNDER LEFT SIDE OF DASH)
J/C
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MAIN SWITCH
MRLY BRAKE PDL SW
NETWORK TRANSCEIVER FAST CONTROLLER AREA
OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR (ON TRANSMISSION HOUSING)
PGM-FI MAIN RELAY 1
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RELAY CONTROL MODULE HORN RELAY
SEDF
SEFD GND DBW M-
SENSOR OUTPUT
SET SWITCH CANCEL SWITCH RESUME SWITCH
THROTTLE ACTUATOR CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
THROTTLE ACTUATOR CONTROL MODULE RELAY (BEHIND GLOVE BOX)
TP SENSOR/THROTTLE ACTUATOR (ON REAR OF ENGINE)
TRANS- MISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY FUSE 21 BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
VCC
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> 3.0l, cruise control circuit, hybrid -> SENSOR OUTPUT
