Honda Accord VII facelift (2005-2008) navigation system Wiring diagrams
This page contains all the electrical diagrams for the component. navigation system, in which he is found in the car Honda Accord VII facelift (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram navigation system (1 of 3)
1 3 XM RECEIVER
AM SIGNAL INPUT
ANTENNA
ANTENNA LEAD CONNECTOR
ANTENNA LEAD JACK
AUDIO UNIT
BLK WIRE
BLU WIRE
BLU/BLK (OR PNK) WIRE
BLU/RED WIRE
BLU/WHT (OR BLU) WIRE
BLU/YEL (OR PPL) WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DEFOGGER SYSTEM
DISPLAY MODULE
FM SIG WINDOW ANTENNA
FM SIGNAL INPUT
FREQUENCY MODULATOR UNIT (UNDER CENTER OF DASH)
FUSE 32
FUSE 33
FUSE 5
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
LT BLU WIRE
LT GRN WIRE
MICU
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK (OR LT GRN) WIRE
PNK WIRE
POWER INPUT ANTENNA OUTPUT
PPL
PPL PNK WIRE
RADIO SW
REAR WINDOW AM SIG WINDOW ANTENNA
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SUB-ANTENNA LEAD
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-DASH FUSE/RELAY BOX CONNECTOR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WINDOW ANTENNA COIL (AT LEFT "C" PILLAR)
XM SATELLITE IN-LINE FUSE 1
XM SATELLITE IN-LINE FUSE 2
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> 3.0l, base radio circuit, except hybrid without rear entertainment (1 of 2) -> NAVIGATION SYSTEM
Wiring diagram navigation system (2 of 3)
+B PG
ACTIVE NOISE CONTROL UNIT (BEHIND AUDIO UNIT)
ATP NP NEP VSP WLP SCS PSW
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DLC (UNDER LEFT SIDE OF DASH)
EPS CONTROL UNIT (BEHIND RIGHT KICK PANEL)
EPS GEARBOX
EPS INDICATOR
EPS MOTOR
EPS TORQUE SENSOR
EPSLD
FUSE 21
GAUGE CONTROL MODULE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
K LINE
M- M+
MULTI- FUSE 22
NAVIGATION SYSTEM
NEP
PCM (UNDER MIDDLE OF DASH)
PVF
RED WIRE
RED/YEL WIRE
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (AT LEFT SIDE OF ENGINE COMPT)
VSSOUT
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit, hybrid -> NAVIGATION SYSTEM
Wiring diagram navigation system (3 of 3)
2 3 PNK WIRE
ABOVE THE KICK PANEL)
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
APP SENSOR (AT RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CKPB
CMP NM
COOLING FANS SYSTEM
CRUISE CONTROL SYSTEM
DLC (ON LOWER LEFT OF DASH,
ECM/PCM (UNDER MIDDLE OF DASH)
EX-L
FTP
FUSE 1
FUSE 19
FUSE 2
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION COIL RELAY
IMOFPR DBWRLY AFSHTCR MRLY FANL FANH BKSW BKSWNC VSV VSSOUT
K-LINE CAN H SCS PSPSW ELD
KNOCK SENSOR (AT LEFT SIDE OF ENGINE)
LT GRN WIRE
LT GRN/RED WIRE
MAP
NAVIGATION SYSTEM
PCS IMRC - IMRC + EGR KS MCS (M/T COUPE) (M/T COUPE)
PGM-FI MAIN RELAY 1
PGM-FI MAIN RELAY 2
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
THROTTLE ACTUATOR CONTROL MODULE RELAY (BEHIND LEFT SIDE OF GLOVE BOX)
TO FUSE 23 (DIAGRAM
UNDER- DASH FUSE/ RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 3.0l, except hybrid (1 of 5) -> NAVIGATION SYSTEM
