Honda Accord VII facelift (2005-2008) display module Wiring diagrams

This page contains all the electrical diagrams for the component. display module, in which he is found in the car Honda Accord VII facelift (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram display module (1 of 3)

Wiring diagram display module for Honda Accord VII facelift (2005-2008) (1 of 3)

Get lifetime access to Honda Accord VII facelift (2005-2008)

ANTENNA BLK WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CABLE REEL CHANNEL DOWN SWITCH CHANNEL UP SWITCH DISPLAY MODULE DRIVER'S DOOR SPEAKER EXCEPT EX-L: NAVIGATION FREQUENCY MODULATOR UNIT (UNDER CENTER OF DASH) FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE LEFT REAR SPEAKER LEFT TWEETER LT GRN WIRE MODE SWITCH NAVIGATION UNIT (IF EQUIPPED) (IN TRUNK, UNDER MIDDLE OF REAR SHELF) NCA WIRE PNK WIRE RADIO REMOTE SWITCH RED/BLK WIRE RG GND RG L+ SH GND RIGHT REAR SPEAKER RIGHT TWEETER SE,EX,EX-L,LX STEERING WHEEL) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) VOICE CONTROL SWITCH VOLUME DOWN SWITCH VOLUME UP SWITCH W/ NAVIGATION WHT WIRE WHT/BLU WIRE WHT/GRN WIRE XM RECEIVER XM SATELLITE IN-LINE FUSE 1 YEL/GRN WIRE YEL/RED WIRE

Go to component -> 2.4l, radio circuit, without rear seat entertainment (2 of 2) -> DISPLAY MODULE

Wiring diagram display module (2 of 3)

Wiring diagram display module for Honda Accord VII facelift (2005-2008) (2 of 3)

Get lifetime access to Honda Accord VII facelift (2005-2008)

1 3 XM RECEIVER AM SIGNAL INPUT ANTENNA ANTENNA LEAD CONNECTOR ANTENNA LEAD JACK AUDIO UNIT BLK WIRE BLU WIRE BLU/BLK (OR PNK) WIRE BLU/RED WIRE BLU/WHT (OR BLU) WIRE BLU/YEL (OR PPL) WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE DEFOGGER SYSTEM DISPLAY MODULE FM SIG WINDOW ANTENNA FM SIGNAL INPUT FREQUENCY MODULATOR UNIT (UNDER CENTER OF DASH) FUSE 32 FUSE 33 FUSE 5 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON LT BLU WIRE LT GRN WIRE MICU NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK (OR LT GRN) WIRE PNK WIRE POWER INPUT ANTENNA OUTPUT PPL PPL PNK WIRE RADIO SW REAR WINDOW AM SIG WINDOW ANTENNA RED WIRE RED/BLK WIRE RED/BLU WIRE SUB-ANTENNA LEAD UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) UNDER-DASH FUSE/RELAY BOX CONNECTOR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WINDOW ANTENNA COIL (AT LEFT "C" PILLAR) XM SATELLITE IN-LINE FUSE 1 XM SATELLITE IN-LINE FUSE 2 YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> 3.0l, base radio circuit, except hybrid without rear entertainment (1 of 2) -> DISPLAY MODULE
