Honda Accord VII facelift (2005-2008) apsa apsb Wiring diagram
This page shows the only wiring diagram for the component.apsa apsb, which is found in the car Honda Accord VII facelift (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram apsa apsb (1 of 1)
APP SENSOR (AT RIGHT SIDE OF ENGINE COMPT)
APSA APSB
ATP-P
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
FUSE 13
FUSE 21
GRN WIRE
GRN/YEL WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
IG KEY SW
IGNITION KEY SWITCH
IGNITION KEY SWITCH/ KEY LIGHT
KEY INTERLOCK SOLENOID
KEY SOL
LT BLU WIRE
LT GRN WIRE
MICU
P PIN SW
PARK PIN SWITCH
PCM (UNDER MIDDLE OF DASH)
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
SEDF
SHIFT LOCK SOLENOID
SLS BKSW ATPP
THROTTLE ACUATOR CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (ON LEFT REAR CORNER OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Shift interlock circuit, hybrid -> APSA APSB
