Car Wiring Diagrams for Courtesy lamps circuit for Honda Accord VII (2002-2006)

AMBIENT LIGHT (EX, EX-L) BLK WIRE BLU WIRE BLU/BLK WIRE CEILING LIGHT CEILING LIGHT CTRL DOOR DOOR COURTESY LIGHT CTRL DOOR OPEN IN DRIVER'S DOOR COURTESY LIGHT DRIVER'S DOOR SWITCH DRIVER'S VANITY MIRROR LIGHT DX, LX EXCEPT DX FRAS COURTESY LT FRONT PASSENGER'S DOOR COURTESY LIGHT FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S VANITY MIRROR LIGHT FUSE 6 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES INDIVIDUAL MAP LIGHTS INSTRUMENT ILLUMINATION CIRCUIT LEFT LEFT REAR DOOR SWITCH LEFT RIGHT LT GRN WIRE LT GRN/RED WIRE MICU OFF OFF ON ON ON OFF OFF REAR JUNCTION BLOCK RED WIRE RED/BLK WIRE RIGHT RIGHT REAR DOOR SWITCH SEDAN TRUNK LATCH IN TRUNK LIGHT UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) WHT WIRE WHT/BLU WIRE YEL/BLU WIRE YEL/GRN WIRE
