Back-up lamps circuit, a/t for Honda Accord VII (2002-2006)
Back-up lamps circuit, a/t
10 6 (2.4L) (3.0L)
2 1 (SEDAN) (COUPE)
2 3 (COUPE) (SEDAN)
2.4L
3.0L
ATPR BACK LT
BACK LT-
BLK WIRE
COUPE
COUPE, SEDAN
ENGINE CONTROLS SYSTEM
FUSE 21
GRN WIRE
HOT IN ON OR START
IGNITION
LEFT BACK-UP LIGHT
MICU
NAVIGATION UNIT
REAR JUNCTION BLOCK
RED WIRE
RIGHT BACK-UP LIGHT
SEDAN
SEDAN, COUPE
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
W/ NAVIGATION
WHT WIRE
WHT/GRN WIRE
