2.4l, cooling fan circuit for Honda Accord VII (2002-2006)
2.4l, cooling fan circuit
A/C CONDENSER FAN MOTOR
A/C CONDENSER FAN RELAY
BLK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/YEL WIRE
ECM/PCM (UNDER MIDDLE OF DASH)
FUSE 11
FUSE 30
FUSE 9
GRN WIRE
HOT AT ALL TIMES
HOT IN ON
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RADIATOR FAN SWITCH
RED WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
