3.0l, starting circuit for Honda Accord VI (1997-2002)
3.0l, starting circuit
A/T GEAR POSITION SWITCH (REAR OF TRANS- AXLE)
ATPNP
BATTERY
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
ELEC- TRICAL LOAD DE- TECTOR (ELD) UNIT
FUSE 41
GRY WIRE
HD IN
IGNITION SWITCH
LOCK (0)
ON (II) (I)
PL IN
POWER DISTRIBUTION SYSTEM
RED/WHT WIRE
STARTER
STARTER CUT RELAY
STARTER MOTOR
STARTER SOLENOID
TRANS- MISSION
UNDER- HOOD FUSE/ RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPT) FUSE 42
WHT WIRE
