Power top/sunroof circuits for Honda Accord VI (1997-2002)
Power top/sunroof circuits
BLK WIRE
BLU WIRE
CLOSE
DRIVER'S DOOR SWITCH
DRIVER'S MULTIPLEX CONTROL UNIT
FRONT PASSENGER'S DOOR SWITCH
FUSE 1
FUSE 51
FUSE 7
FUSE 9
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
MOON ROOF CLOSE RELAY (ABOVE LEFT KICK PANEL)
MOON ROOF MOTOR (UNDER HEADLINER, ABOVE CENTER OF REAR WINDOW)
MOON ROOF OPEN RELAY (ABOVE LEFT KICK PANEL)
MOONROOF LIMIT SWITCH (ABOVE CENTER REAR OF HEADLINER)
MOONROOF SWITCH
MOONROOF SWITCH LIGHTS
ORG/ WIRE
PASSENGER'S MULTIPLEX CONTROL UNIT
PNK WIRE
POWER WINDOW RELAY
RED WIRE
RED/BLK WIRE
TILT
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
