Entry light timer circuit, ex for Honda Accord VI (1997-2002)

Entry light timer circuit, ex

Get access

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE CEILING LIGHT DOOR MULTIPLEX CONTROL UNIT (IN MASTER POWER WINDOW SWITCH) DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR SWITCH DRIVER'S MULTIPLEX CONTROL UNIT EXTERIOR, INTERIOR LIGHT SYSTEMS FRONT PASS- ENGER'S DOOR SWITCH RIGHT REAR DOOR SWITCH FUSE 11 FUSE 47 FUSE 9 GRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY LIGHT IGNITION KEY SWITCH (SHOWN KEY REMOVED) LEFT REAR DOOR SWITCH OFF ON DOOR PASSENGER'S MULTIPLEX CONTROL UNIT PNK (NOT USED) WIRE PNK WIRE RED/BLK WIRE SECURITY SYSTEM CONNECTOR (OPTION) STEERING LOCK TAILLIGHT RELAY UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT) UNLOCK LOCK WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE
