3.0l, cooling fan circuit for Honda Accord VI (1997-2002)
3.0l, cooling fan circuit
1 2 3 4 5 6 7 8 RLY CTRL IGN ON RLY CTRL GROUND FAN SW B BATT IN IGN ON FAN SW A
A/C PRESSURE SWITCH (BEHIND RIGHT SIDE FRONT BUMPER) LO HI
AUTO A/C MANUAL A/C
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CLIMATE CONTROL UNIT HEATER CONTROL PANEL
CONDENSER FAN RELAY
DRIVER'S UNDERDASH FUSE/RELAY BOX FUSE 6
FUSE 57 FUSE 58
GRN WIRE
HOT AT ALL TIMES
HOT IN ON FUSE 3
HOT IN ON OR START
PASSENGER'S UNDERDASH FUSE/RELAY BOX (NOT USED)
POWERTRAIN CONTROL MODULE (FORWARD OF FLOOR CONSOLE)
RADIATOR FAN CONTROL MODULE (BEHIND GLOVE BOX)
RADIATOR FAN MOTOR CONDENSER FAN MOTOR
RADIATOR FAN RELAY
RADIATOR FAN SWITCH A (ON THERMOSTAT COVER)
RADIATOR FAN SWITCH B (ON FRONT OF LEFT CYLINDER HEAD)
RED WIRE
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
